HOW TO REMOVE AND INSTALL THE THIRD ROW SEAT (7-SEATERS)*

1. Fold down the seatback of the third row seat while puliing
up the seatback reclining lever ( ).
2. Remove the seat rail covers ( )
CAUTION
• Be careful not to drop the seat when removing it. It may cause a
personal injury.
• Make sure that the seat is securely engaged on the rail during
installation.
• Do not put any luggage between the 2nd and 3rd row if the 3rd row
seat has been removed and the 2nd row seat is rotated. It may cause
serious personal injury when the brake is applied suddenly. Please
put the luggage only when the seat is installed in normal position.
7 - 1 8
Page 18
3. Slide the third row seat to its rear end (arrow direction)
while pulling up the seat sliding lever ( ).
4. Carefully remove the third row seat from the rail by using
the hand grips ( , ) on the seat as shown in the figure.
5. Install the seat in the reverse order of removal.
