Immobilizer Indicator
This indicator indicates the operating
conditions of immobilizer system. This
indicator comes on when the ignition
key is communicating with the engine control unit (during
engine starting) and goes out after starting the engine.
CAUTION
If this indicator blinks, it may indicate that there is something
wrong in the immobilizer system. Have the system checked
by Ssangyong Dealer or Ssangyong Authorized Service
Operation.
4WD CHECK Warning Light*
This warning light comes on when the
ignition switch is turned to "ON" and
should go out if the system is normal.
If "4WD CHECK" warning light stays on, have the 4WD
system checked by Ssangyong Dealer or Ssangyong
Authorized Service Operation.
CAUTION
If "4WD CHECK" warning light stays on or "4WD LOW" indi-
cator blinks continuously, have the 4WD system checked by
Ssangyong Dealer or Ssangyong Authorized Service
Operation.
Page 9
4WD Low Indicator*
* When shifting the driving mode between
"4WD LOW" and "4WD HIGH", this indica-
tor blinks until the shifting operation is
completed. After completion of mode change, the indicator
goes on. After completion of mode change to 4WD HIGH, the
indicator goes out.
4WD High Indicator
(For Part Time 4WD)
This indicator comes on when the 4WD HIGH
mode is selected by pushing 4H switch.
Shift the driving mode from 2WD to 4WD HIGH only when
the vehicle speed is under 70 km/h.
NOTE
When shifting the driving mode from 4WD LOW to 4WD HIGH, this
indicator will blinks until the shift is completed. After completion of
shift, the indicator stays on. The indicator comes on without blink-
ing when shifting from 2WD to 4WD HIGH.
INSTRUMENT PANEL
2006-10-02, ¿ÀÀü 11:05
5-9
