Wiper Blade Replacement - SSANGYONG RODIUS Owner's Manual

WIPER BLADE REPLACEMENT

1. Lift the wiper arm up from the
windshield.
Front wipers
13-24
Page 24
2. Press the safety button ( ).
CAUTION
• Do not open the hood when the wiper arm is lifted up. The wiper and hood
may be damaged.
• Do not operate the wiper when the washer fluid reservoir is empty.
• Since there is no way to successfully remove traces of oil or grease
from any glass, be certain not to apply any polish containing oil to the
windshield of your vehicle since this will result in streaks which impair
vision. Contamination of either the window or the wiper blades with for-
eign matter can reduce the effectiveness of the windshield wipers.
Rear wiper
WARNING
• Never drive your vehicle when the wipers are not properly working.
• Do not touch the running wipers. It may cause a personal injury.
3. Slide the blade down and remove it
from the arm.
4. Install a new blade.
5. Put the wiper arm down to its park-
ing position.
