BATTERY VOLTAGE

BATTERY VOLTAGE
Charging Level
It indicates the current battery voltage by 0.1 V.
When the battery voltage goes below 12.0 V, current display
is changed to battery voltage mode and "LOW VOLTAGE"
message flashes at every 10 seconds.
CAUTION
• Start the engine and charge the battery voltage when the battery
voltage is below 12.0 V.
• When starting the engine, the battery voltage is temporarily
decreased.
• If the charging level in display is not increased even when the
engine is running, have the system checked at Ssangyong Dealer
or Ssangyong Authorized Service Operation.
Page 31
Battery Voltage
Battery voltage Indication
Over 12.0 V
(Fully charged)
11.9 ~ 11.0 V
10.9 ~ 10.0 V
9.9 ~ 9.0 V
INTERIOR SWITCHES
2006-10-02, ¿ÀÀü 11:05
4-31
