Figure 11. Entering Resident's Names - Mircom TX3 Series User Manual

Figure 11.
Note:
For example, to enter the last name "Doe",
3.
Table 1: List of Screens
Database Menu
Enter Resident Name
Enter Apt No
[_ _ _ _]
Enter Dial Code
_ _ _ _
Enter Keyless Code
[_ _ _ _]
Enter Relay Code
[_ _ _ _]
Enter Telephone #
[____________]
Hide Res Name
[x] Display
Version 1.1 Telephone Access System User Guide
LT-968 Copyright 2012
Entering Resident's Names
If you accidentally enter the wrong character while configuring a
name, press * once to backspace or press 0 to delete the letter.
a. Press "3" four times for the upper case letter "D".
b. Press "6" three times for the letter "o".
c. Press "3" two times for the letter "e".
d. Press the telephone key to save and continue.
Once you have entered the name, press the telephone key to accept. The
following screens will appear as shown in Table 1.
NSL ADC
System System
YES YES
YES YES
YES YES
YES YES
YES N/A
N/A YES
YES YES
Explanation/Description
Enter the resident's name. The name must be
unique and a maximum of 15 characters.
Enter the resident's apartment number (up to 4
digits).
Enter the resident's dial code (up to 4 digits).
Enter the assigned keyless code, up to 6 digits
(if used). See below for using keyless entry
codes.
Enter the resident's assigned relay code.
Note: Relay codes start at 1 for the first relay,
up to 1535.
Enter the resident's telephone number (up to
18 digits including a comma that is used as 1
second delay). Use the up arrow key for a
comma and the down arrow key for a dash
which is optional. Press the Enter (telephone
key) to accept the telephone number.
This feature turns the resident information
display ON or OFF. When OFF the resident's
information is only displayed in configuration
mode.
Configuration
23 (42)
