2.9
DTMF Sensitivity setup
The DTMF sensitivity feature allows the resident to change how sensitive the
TX3 unit is to receiving DTMF signals. DTMF sensitivity can be set from 1 to 8.
A sensitivity of 1 indicates the lowest sensitivity while 8 is the highest sensitivity.
The default sensitivity is 5.
To set the DTMF
27. DTMF Sensitivit
- DTMF Sensitivity -
[ 005 ]
Figure 6.
You have successfully set the DTMF sensitivity. The display now returns to the
configuration menu.
Version 1.1
Telephone Access System User Guide
LT-968
Copyright 2012
sensitivity
1.
Press
(scroll up) or
"DTMF Sensitivit".
2.
Press
when the arrow is beside "DTMF Sensitivit".
The display enters DTMF Sensitivity setup.
3.
Press
(scroll up) or
the sensitivity level.
4.
Press
to save and continue.
DTMF Sensitivity
Configuration
(scroll down) to find
(scroll down) to select
17 (42)
Hide quick links:
Advertisement
Table of Contents
Need help?
Do you have a question about the TX3 Series and is the answer not in the manual?
Questions and answers
Je ne sis pas capable de rentrer dans le programme ou on peut retirer , ajouter, changer le nom et 3 de téléphone des condos
To access the programming for the Mircom TX3 Series and add, remove, or change names and phone numbers:
1. Use the main entry panel keypad.
2. Navigate to the configuration menu.
3. Select the option to add, delete, or edit records.
4. Follow the on-screen instructions to enter or modify resident names and dial codes using the alphanumeric keypad.
5. Confirm changes by pressing the telephone (enter) key.
The system allows adding up to 200 names at a time, depending on the model's capacity (200, 1000, or 2000 names).
This answer is automatically generated
