6. Optical Specifications

6.1. Laser Scan Specifications

Parameter
Light-emitting element
Emission wavelength
Light output
Scanning method
Scanning speed
Scan angle
Notes:
Refer to chapter 15, "Trigger and Read Options," to read about the scan modes.
Refer to chapter 7, "Technical Specifications," to read about scanning performance.

Tilt of Laser Scan Line

6.1.1.
Scanning tilt is the vertical difference between the ends of a laser scan line.
•
•
Measurement is done at the center of the laser scan line.

Curvature of Scan

6.1.2.
Scanning curvature is the maximum difference between the laser scan line and
the line between the ends of the laser scan line.
•
•
Specification
Red laser diode
650 ±10 (25° C)
1.0 or less
Bi-directional scanning
Scan angle: 54 ±5
Read angle: 44 (Min)
Up to 0.92° in a vertical direction from the scan origin (mirror motor mirror).
Up to 2.46 mm when measured at 150 mm from the scan origin.
Up to 1.17° in a vertical direction from the scan origin (mirror motor mirror).
Up to 3.06 mm when measured at 150 mm from the scan origin.
11
Unit
—
nm
mW
—
100 ±20 scans/s
°
°
