Output Specifications

5.3.2.
Output voltage
Power ripple
Maximum current
Short-circuit protection
Conditions
•
Connect 1Ω resistance to a power supply line in series and measure the current
by the voltage between both ends of resistance.
•
Power supply voltage is measured at a connector terminal area.
•
The current value depends on the interface type and host computer to which the
device is connected.

6. Optical Specifications

6.1. CCD Specifications

Parameter
Light-emitting element
Emission wavelength
Scanning method
Scanning speed
Number of pixels
Notes:
Refer to chapter 15, "Trigger and Read Options," to read about the scan modes.
Refer to chapter 7, "Technical Specifications," to read about scanning performance.
Parameter
6.0 V ±5%
120 m Vp-p max. (rated load)
2 A
Available
Specification
Red LED
630 ±10 (25° C)
CCD Linear Image Sensor
200 ±20
11
Value
Unit
—
nm
—
scans/s
2500 —
