HP c-Class Overview page 41

QuickSpecs
Technical Specifications
users guide at: http://h71028.www7.hp.com/enterprise/cache/316682-0-0-0-121.html
Server Blade, Power Supply and Fan Population Guidelines Server Blade, Power Supply and Fan Population Guidelines Server Blade, Power Supply and Fan Population Guidelines Server Blade, Power Supply and Fan Population Guidelines
Fan bay numbering Fan bay numbering
Fan bay numbering Fan bay numbering
Number of Fans Number of Fans Number of Fans Number of Fans
NOTE: NOTE: For correct operation fans and server blades must be installed in the correct bays. The Onboard Administrator will ensure
NOTE: NOTE:
that fans and blades are correctly placed before allowing systems to power on.
c7000 Enclosure - Fans must be placed in the following bays c7000 Enclosure - Fans must be placed in the following bays c7000 Enclosure - Fans must be placed in the following bays c7000 Enclosure - Fans must be placed in the following bays
4
6
8
10
c7000 Enclosure - Half-height server blade bay numbering c7000 Enclosure - Half-height server blade bay numbering c7000 Enclosure - Half-height server blade bay numbering c7000 Enclosure - Half-height server blade bay numbering
DA - 12517 Worldwide — Version 19 — September 15, 2008
HP BladeSystem c-Class Infrastructure HP BladeSystem c-Class Infrastructure HP BladeSystem c-Class Infrastructure HP BladeSystem c-Class Infrastructure
Fan Bays Used Fan Bays Used Fan Bays Used Fan Bays Used
4, 5, 9, 10
3, 4, 5, 8, 9, 10
1, 2, 4, 5, 6, 7, 9, 10
1, 2, 3, 4, 5, 6, 7, 8, 9, 10
Page 41
