HP c-Class Overview page 36

QuickSpecs
Storage
Figure 1 Figure 1 Figure 1 Figure 1 Installing a tape blade adjacent to a half-height
server blade.
HP StorageWorks Ultrium 448c & 920c Tape Blade HP StorageWorks Ultrium 448c & 920c Tape Blade HP StorageWorks Ultrium 448c & 920c Tape Blade HP StorageWorks Ultrium 448c & 920c Tape Blade
Description Description Description Description
HP Ultrium Tape Blade HP Ultrium Tape Blade HP Ultrium Tape Blade HP Ultrium Tape Blade
NOTE: Connected NOTE: NOTE: NOTE:
adjacent to a half-height
server blade (Figure 1)
HP Ultrium Tape Blade HP Ultrium Tape Blade HP Ultrium Tape Blade HP Ultrium Tape Blade
NOTE: NOTE: Connected NOTE: NOTE:
adjacent to a full-height
server blade (Figure 2)
Quantity Quantity Quantity Quantity
Supported Supported Supported Supported
Up to 8 per HP Odd or Even slots next to
BladeSystem c-Class
c7000 Enclosure
Up to 4 per HP Odd or Even slots next to
BladeSystem c-Class partner server blade (lower
c7000 Enclosure
DA - 12517 Worldwide — Version 19 — September 15, 2008
HP BladeSystem c-Class Infrastructure HP BladeSystem c-Class Infrastructure HP BladeSystem c-Class Infrastructure HP BladeSystem c-Class Infrastructure
Figure 2 Figure 2 Figure 2 Figure 2 Installing a tape blade adjacent to a full-height
server blade.
Position Position Position Position
Supported Supported Supported Supported
partner server blade
bays only)
Comments Comments Comments Comments
A tape blade supports one partner server
blade, and one partner server blade
supports one tape blade.
Identify the partner server blade to be
installed with the tape blade. The two
blades always occupy a pair of slots, as
follows: 1 & 2, 3 & 4, 5 & 6, 7 & 8, 9 &
10, 11 & 12, 13 & 14, 15 & 16 (See
Figure 1).
If the partner server blade is installed in an
odd-numbered bay, the tape blade is
installed in the adjacent even-numbered
bay to the right.
If the partner server blade is installed in an
even-numbered bay, the tape blade is
installed in the adjacent odd-numbered
bay to the left.
A tape blade supports one partner server
blade, and one partner server blade
supports one tape blade.
When partnering a tape blade with a full
height server blade, an HP PCI Express
Page 36
