HP c-Class Overview page 16

Hp bladesystem c-class infrastructure

Hide thumbs Also See for c-Class:

QuickSpecs

Configuration Information Factory Integrated Models

HP BladeSystem

c-Class FC SAN

Interconnects

HP BladeSystem

InfiniBand Interconnects

Step 4: Select rack power distribution for single-phase models

NOTE: A pair of PDUs must be ordered for AC Feed redundancy.

NOTE:

HP Monitored Power

Distribution Unit

HP Modular Power

Distribution

Units

HP 10Gb Ethernet BL-c Switch

NOTE:

NOTE: The purchase the HP 10Gb Ethernet BL0c Switch, also requires the purchase

NOTE:

of one (1) HP NC512m Dual Port 10GbE Multifunction BL-c Adapter (P/N 440910-

B21) per server blade that requires 10Gbit support.

HP 10GbE BLc Advanced Functionality Software

NOTE: Provides additional feature functionality such as Hot Links, PVLAN Edge and

NOTE:

IGMPv3 Snooping. Purchase of this SW entitles users to three years of additional

software upgrades as made available. This option may be purchased at any time.

NOTE:

NOTE: The HP BladeSystem c-Class Network Interconnects ship as single units. The

NOTE:

above interconnects must be ordered in quantities of two for redundancy support.

HP 4Gb Virtual Connect Fibre Channel Module for c-Class BladeSystem

16 port FC Pass-thru Module for c-Class BladeSystem

HP Brocade 4/12 SAN Switch

HP Brocade 4/24 SAN Switch Power Pack

HP Brocade 4/24 SAN Switch

HP Brocade 4/12 SAN Switch Upgrade LTU

Cisco MDS 9124e 12-port Fabric Switch

Cisco MDS 9124e 24-port Fabric Switch

Cisco MDS 9124e 12-port Upgrade LTU

HP 4X DDR IB Switch Module for HP c-Class BladeSystem

HP 17.3 kVA S348 Monitored PDU- single input, 3Ø, 48A (NA/JPN)

HP 22 kVA S332 Monitored PDU- single input, 3-phase, 32A (INTL)

HP 8.6 kVA S1324 Monitored PDU- single input, 3Ø, 24A (NA/JPN)
