QuickSpecs

Related Options

c3000 Enclosure Options HP c-Class Replacement Enclosure Miscellaneous Blanks kit

c3000 Enclosure Options

c7000 Enclosure Options

c7000 Enclosure Options HP Redundant Onboard Administrator Option

c-Class Power Supply

c-Class Active Cool Fan

HP BladeSystem c7000 Enclosure, Three-Phase North America/Japan with 6 Power

Supplies,6 Fans with 8 Insight Control Environment 30 day Trial Licenses

HP BladeSystem c7000 Enclosure, Three-Phase International with 6 Power Supplies,6

Fans with 8 Insight Control Environment 30 Day Trial Licenses

NOTE: All c7000 BTO enclosures will ship with 12 server blanks. Additional server

NOTE:

blanks may be purchased if required. CTO enclosures will ship with the required

number of server blanks.

NOTE:

NOTE: Contains 1 each of Power Supply Blank, Interconnect Module Blank, Local

KVM option blank, DVD Blank, Active Cool Fan Blank, and c3000 minidivider)

NOTE: This kit should only be ordered to replace lost or damaged blanks.

NOTE:

HP c-Class Replacement Server Blank and Coupler Option Kit (contains 1 x half-

height server blank with coupler)

NOTE:

NOTE: The coupler allows half-height server blanks to be coupled together to create

NOTE:

a full-height server blank.

NOTE:

NOTE: This kit should only be ordered to replace lost or damaged blanks.

NOTE:

HP BLc3000 Rack Rails

NOTE: For use with the c3000 rack-able (437507-B21) model.

NOTE:

HP c7000 Enclosure 10K Rack Ship Bracket Option Kit

NOTE:

NOTE: The shipping bracket is required when shipping a c7000 enclosure when

NOTE:

installed in a rack. It is not required for normal operation.

HP c7000 Replacement Enclosure Miscellaneous Blanks kit (contains 1 each of Power

Supply Blank, Interconnect Module Blank, Onboard Administrator Blank, Active Cool

Fan Blank)

NOTE:

NOTE: This kit should only be ordered to replace lost or damaged blanks.

HP c-Class Server Blank and Coupler Option Kit (contains 1 x half-height server blank

with coupler)

NOTE: The coupler allows half-height server blanks to be coupled together to create

NOTE:

a full-height server blank.

NOTE: This kit should only be ordered to replace lost or damaged blanks.

NOTE:

HP c7000 Enclosure Hot-Plug Power Supply Option Kit (supplied with IEC C20 - C19

jumper cord)

HP 1200W AC Power Supply

NOTE: Supports the c3000 c-Class Server Blade Enclosure.

NOTE:

NOTE: Includes a C13 to C14 PDU power cord.

NOTE:

NOTE: For a full enclosure, order 2 additional power supplies (4 total) in a Power

NOTE:

Supply Redundant (N+1) configuration; order 4 additional power supplies (6 total) in

an AC Redundant (N+N) configuration.

NOTE: For c-3000 Low-line Power Cords, please order the appropriate power cord

NOTE:

for your countries standard electrical outlets. Please see Step 5 above for power cord

part numbers.

HP Active Cool Fan Option Kit

NOTE:

NOTE: A minimum 4 Active Cool fans is required, 8 Active Cool fans can support a

NOTE:

full blade enclosure, 10 Active Cool fans should be ordered for reduced power

consumption and noise reduction.

NOTE: Supports the c3000 and c7000 c-Class Server Blade Enclosures.

NOTE:

DA - 12517

Worldwide — Version 19 — September 15, 2008

HP BladeSystem c-Class Infrastructure

412133-B22

403318-B22

412148-B21

412150-B21

437576-B21

412142-B21

433718-B21

412148-B21

412150-B21

412138-B21

437572-B21

412140-B21

Page 19
