GENICOM LN45 and
Intelliprint mL450 User
Guide
Aug 01
Genicom
Publication No. GEG-99126

Advertisement

Table of Contents
loading

Related Manuals for Genicom Intelliprint ML450

Summary of Contents for Genicom Intelliprint ML450

  • Page 1 GENICOM LN45 and Intelliprint mL450 User Guide Aug 01 Genicom Publication No. GEG-99126...

  • Page 2: Proprietary Statement

    Copyright Notice This manual is Copyrighted © 2001 by GENICOM LLC, 4500 Daly Drive, Suite 100, Chantilly, VA 20151. All Rights Reserved. This manual may not be copied in whole or in part, nor transferred to any other media or language, without the express written permission of GENICOM LLC.
  • Page 3 This manual consists of 7 chapters and 5 appendices as follows: Chapter 1 Unpacking and Installing Your Printer Describes a suitable location for your laser printer and how to unpack and install it. Be sure to read this chap- ter before setting up the printer.. Chapter 2 Printer and Options Parts and Functions Describes the parts of the printer and paper handling options and their functions.
  • Page 4 Appendix E GENICOM Customer Support and Part Numbers This appendix lists the part numbers for GENICOM LN45 and Intelliprint mL450 printers, options, and consumables. To order parts, contact your local authorized GENICOM dealer. This appendix will familarize you with GENICOM LLC and how to contact GENICOM for support.

  • Page 5: Table Of Contents

    Extended Configuration (floor-standing) Manual Conventions Chapter 1 Unpacking and Installing Your Printer About this Chapter Installation Precautions Environment Space requirements Top View of Printer (standard configuration) Top View of Printer (when options are installed) Aug 01 -iii Genicom Publication No. GEG-99126...
  • Page 6 GENICOM LN45 and Intelliprint mL450 Installation Guide Unpacking the Printer Installing the EP Cartridge For standard configuration Adding paper to the 500-sheet universal paper cassette Connecting the Parallel Cable Connecting the Ethernet Cable Connecting the Power Cord Turning the Printer On...
  • Page 7 LCD Display LED Indicators Pushbuttons Aug 01 GENICOM LN45 and Intelliprint mL450 Installation Guide Top View of Long Edge Feeds Long Edge Duplex Bind in Portrait Orientation Short Edge Duplex Bind in Portrait Orientation Long Edge Duplex Bind in Landscape Orientation...
  • Page 8 GENICOM LN45 and Intelliprint mL450 Installation Guide Navigating the Control Panel Menus Menu Structure Paper Menu Interface Menu PS Menu PCL Menu System Menu Quality Menu Functions Menu FLASH Menu DISK Menu Status Menu Chapter 5 Printer Consumables, Cleaning and...
  • Page 9 Using DRAM DIMMs, FLASH DIMMs and Power-on Files About this Chapter Installing DRAM Memory DIMMS Installing a FLASH DIMM Module Using the Power-On Files Feature Power-on Files Defined Aug 01 GENICOM LN45 and Intelliprint mL450 Installation Guide 6-12 6-13 6-14 6-14 6-15 6-15 6-15...
  • Page 10 GENICOM LN45 and Intelliprint mL450 Installation Guide Appendix A General Information About this Appendix Specifications Main Unit Printable Area Normal printing Wide printing Appendix B Safety Notes and Regulatory Compliances About this Appendix Safety Notes Power Source, Power Cord and Accessory Cable Precautions...
  • Page 11 Your GENICOM Vendor Your Application Vendor Internet GENICOM Technical Support GENICOM Service GENICOM World-wide Offices GENICOM LN45 and Intelliprint mL450 Part Numbers Printers Paper Handling and Other Options Network Interfaces DRAM, FLASH DIMM, Barcode and Hard Disk Drive Options User Publications...
  • Page 12 GENICOM LN45 and Intelliprint mL450 Installation Guide Publication No. GEG-99126 Aug 01 Genicom...

  • Page 13: Preface

    Preface In this Chapter . . . “Welcome” on page 2 " “Features” on page 2 " “Standard Configurations” on page 3 " “Manual Conventions” on page 5 " Aug 01 Genicom Publication No. GEG-99126...

  • Page 14: Welcome -2

    High-speed and high-quality printing Both the LN45 and the Intelliprint mL450 have paper output of 45 pages per minute with a resolution of up to 600 x 600 dpi, assuring razor-sharp output of graphics and text, even at very small point sizes.

  • Page 15: Standard Configurations -3

    Standard Configurations The LN45 or Intelliprint mL450 printer can be ordered in the following two standard configurations: Base Configuration (for table-top use) Memory: 64 Mbytes RAM Memory Resolutions: 300 x 300 dpi and 600 x 600 dpi Paper Input: Two 500-sheet universal paper trays and one 50-sheet Multi-Purpose Bypass Feeder for...

  • Page 16: Extended Configuration (Floor-Standing) -4

    50 sheets). Stapling and 3-hole punch functions can be used in conjunction to provide a 3-hole punched and stapled finished document of up to 50 sheets. NOTE: The LN45 Bundle, and the Intelliprint mL450 Bundle printers come standard with Ethernet, Duplexer, High Capacity Feeder, and the Finisher/Stapler Unit. Publication No. GEG-99126...

  • Page 17: Manual Conventions -5

    Caution: Cautions present information that you need to know to avoid equipment damage, process failure, or extreme annoyance. Pay special attention to these sections and read them fully before operating the printer. GENICOM will not be responsible for any problems or damage arising from improper use.
  • Page 18 GENICOM LN45 and Intelliprint mL450 User Guide Manual Conventions Publication No. GEG-99126 Aug 01 Genicom...

  • Page 19: Unpacking And Installing Your Printer

    “Printing a Configuration Summary” on page 1-19 " “Printing a Test Page” on page 1-21 " “Printing PCL and PostScript Font Lists” on page 1-22 " “Turning the Printer Off ” on page 1-23 " Aug 01 Genicom Publication No. GEG-99126...

  • Page 20: About This Chapter

    GENICOM LN45 and Intelliprint mL450 User Guide Installation Precautions About this Chapter Describes a suitable location for your laser printer and how to unpack and install it. Be sure to read this chap- ter before setting up the printer. Installation Precautions Before unpacking your laser printer, it is recommended that you read the following to assist locating a suit- able spot for your new laser printer.

  • Page 21: Top View Of Printer (Standard Configuration)

    Top View of Printer (standard configuration) Top View of Printer (when options are installed) (630) Aug 01 GENICOM LN45 and Intelliprint mL450 User Guide 1-3 41.7 (1060) 14.3 (364) 42.7 (1084) Measurements in inches (mm) 24.8 81.5 (2069) Measurements in inches (mm)

  • Page 22: Unpacking The Printer

    GENICOM LN45 and Intelliprint mL450 User Guide Unpacking the Printer Unpacking the Printer Cut the shipping straps off the exterior carton. Remove the four plastic inserts at the base of the shipping container by pulling on the tabs of each insert.

  • Page 23: Aug 01

    B-3. NOTE: Save the carton and packing materials for later use in case you need to ship the printer at a later time. It is particularly important that you save the wooden shipping pallet. CAUTION: Never attempt to ship your printer without using the wooden pallet. Severe dam- age may occur.

  • Page 24: Installing The Ep Cartridge

    GENICOM LN45 and Intelliprint mL450 User Guide Installing the EP Cartridge When you unpack the printer, make sure that all the items shown below are included. If any items are missing or damaged, contact your point of purchase. GENICOM LN45 and Intelliprint mL450 ...

  • Page 25: For Standard Configuration

    Hold the EP cartridge horizontally and gently shake it 5 to 6 times to evenly distribute the toner inside. Uneven toner distribution may degrade print quality. If the toner has not been properly freed by shak- Aug 01 GENICOM LN45 and Intelliprint mL450 User Guide 1-7 For standard configuration Genicom...
  • Page 26 GENICOM LN45 and Intelliprint mL450 User Guide Installing the EP Cartridge ing the cartridge, a noise may be heard when turning on the printer and the EP cartridge may be dam- aged. Open the front cover as indicated. WARNING: Never touch the fuser area (where a label indicating high temperature is located).
  • Page 27 While holding the orange handle with one hand, gently push the cartridge all the way into the printer. CAUTION: Do not touch any parts inside the printer. Make sure the cartridge is seated prop- erly. Gently pull out the sealing tape in the direction of the arrow.

  • Page 28: Adding Paper To The 500-Sheet Universal Paper Cassette

    1-10 GENICOM LN45 and Intelliprint mL450 User Guide Adding paper to the 500-sheet universal paper cassette Close the front cover and the upper left cover. NOTE: When closing the upper left cover, do not use the latch on the cover. Instead, follow the instruction label on the cover and push the recommended location.
  • Page 29 Do not use paper with creases or wrinkles. When using special paper, fan it before insertion. Gently lift up the length guide, and slide it all the way until it stops. Aug 01 GENICOM LN45 and Intelliprint mL450 User Guide 1-11 For standard configuration Genicom...
  • Page 30 1-12 GENICOM LN45 and Intelliprint mL450 User Guide Adding paper to the 500-sheet universal paper cassette While pressing down the gray handle, slide the side guide all the way until it stops. Align the four corners of the paper and place the paper in the cassette. The paper should enter easily between the guides.
  • Page 31 Adjust the guide to the paper size correctly; otherwise paper may not be transported correctly and may result in a paper jam. Align the edges of the paper stack Aug 01 GENICOM LN45 and Intelliprint mL450 User Guide 1-13 For standard configuration Genicom Publication No. GEG-99126...

  • Page 32: Connecting The Parallel Cable

    Connecting the Parallel Cable Attach an optional parallel cable to the parallel port on the rear of your printer. Attach the other end of the parallel cable to the parallel port on your PC or workstation.

  • Page 33: Connecting The Ethernet Cable

    Connecting the Ethernet Cable Attach appropriate cable to your Ethernet hub. Attach the opposite end of the cable to the ethernet port on the printer. Connecting the Power Cord Connect the printer to an AC outlet as described below. WARNING: To prevent the risk of electric shock, never touch the power cord or plug with wet hands.
  • Page 34 GENICOM LN45 and Intelliprint mL450 User Guide Connecting the Power Cord Verify that the power switch of the printer is set to the [ O ] (off) position then insert the plug of the power cord into the AC outlet.

  • Page 35: Turning The Printer On

    Power On Self Test ends with the top line of the display reading: NOTE: While turned on, the printer will go into the standby state if it remains idle for a period of time.If an error message appears, Selecting a Display Language The default language for all LCD display messages and the Configuration Summary and Test Page is English.

  • Page 36: Installing Printer Drivers

    Installing Printer Drivers Installing Printer Drivers and other Software for UNIX and Windows To install printer drivers and other software for UNIX and Windows, go to the SOFTWARE folder located on the Electronic Library CD-ROM. The SOFTWARE folder contains the following subfolders: Drivers Folder "...

  • Page 37: Installing Printer Drivers For Macos

    The UnixSW folder contains GENICOM UNIX Printing Software, which is an enhanced print filter and network socket driver that allows you to take advantage of all of the printing features of your printer. Refer to the INSTSALL.PDF file included in this folder for more information about installing and using Gentian UNIX Printing Software.
  • Page 38 1-20 GENICOM LN45 and Intelliprint mL450 User Guide Printing a Configuration Summary Publication No. GEG-99126 Aug 01 Genicom...

  • Page 39: Printing A Test Page

    Printing a Test Page Your printer can print a test page that lists the indicates, grey scale, resolution settings, page counter, and other relevant information about your printer. To print a Test Page, follow these steps: From the Ready status, press MENU, the control panel display will read:...

  • Page 40: Printing Pcl And Postscript Font Lists

    Printing PCL and PostScript Font Lists Printing PCL and PostScript Font Lists Your printer has the capability of printing lists of all installed PCL or PostScript fonts. To print a Font List, follow these steps: From the Ready status, press MENU, the control panel display will read:...

  • Page 41: Turning The Printer Off

    Press SELECT. A multi page resident Font List will print. Examples of a PCL and PostScript Font Lists appears in Appendix C of this manual. Turning the Printer Off Remember to turn off the printer at the end of day or when the printer will not be used for an extended period of time. NOTE: When the printer is turned off, all print data still in memory will be erased.
  • Page 42 1-24 GENICOM LN45 and Intelliprint mL450 User Guide Turning the Printer Off Publication No. GEG-99126 Aug 01 Genicom...

  • Page 43: Printer And Options Parts And Functions

    Printer and Options Parts and Functions In this Chapter . . . “About this Chapter” on page 2-2 " “Main Unit” on page 2-2 " “Options” on page 2-6 " Aug 01 Genicom Publication No. GEG-99126...

  • Page 44: About This Chapter

    Main Unit About this Chapter Describes the parts of the printer and paper handling options and their functions. A discussion of the paper path is also included. Also describes all available options and consumables for your printer and their respec- tive part numbers.

  • Page 45: Rear View

    NOTE: The upper left cover can be closed only when the EP cartridge is installed in the printer. Do not close it when the EP cartridge is not inside the printer. Rear View DUPLEXER connector OUTPUT connector TRAY connector Power cord receptacle...

  • Page 46: Controller

    GENICOM LN45 and Intelliprint mL450 User Guide Main Unit Controller Optional Network Interfaces Parallel Port Ethernet Reset Switch ON - 100BaseT Connection active OFF - 10BaseT Connection active ON - Indicates Ethernet connection is active. RJ45 Ethernet Port Publication No. GEG-99126...

  • Page 47: Inside The Printer

    Never touch the fuser area where a label indicating high temper- ature is located (such as that shown below), or else burns may result Aug 01 GENICOM LN45 and Intelliprint mL450 User Guide 2-5 Fuser Fixes toner onto the paper...

  • Page 48: Options

    GENICOM LN45 and Intelliprint mL450 User Guide Options Options The above illustration show the printer with the standard cassette feeders, duplexer, and face-up tray installed. Duplexer Duplexer latch High Capacity Feeder (HCF) unit (Trays 3, 4, 5) Publication No. GEG-99126 For printing on both sides of a sheet.
  • Page 49 The above illustration shows the printer with the Finisher/Stapler unit installed. Finisher/Stapler unit Aug 01 GENICOM LN45 and Intelliprint mL450 User Guide 2-7 The optional envelope feeder can be hold up to about 100 envelopes. High capacity finisher (stacker) and stapler for automatic stapling of printed sheets.
  • Page 50 Options NOTE: Additional options such as network interfaces, memory DIMMs, consumables and user publications are available for your printer. For a complete list of available options, part numbers and ordering information see Publication No. GEG-99126 ”Appendix E GENICOM Customer Support and Part Numbers”...

  • Page 51: Understanding Paper, Paper Paths, Paper Delivery And Paper Loading

    “Adding paper to the 500-sheet paper cassette, Tray 1 or Tray 2” on page 3-16 " “Adding paper to the multi bypass feeder” on page 3-20 " “Adding paper to the HCF unit (2500-sheet)” on page 3-22 " “Loading envelopes into the envelope feeder” on page 3-29 " Aug 01 Genicom Publication No. GEG-99126...

  • Page 52: About This Chapter

    To obtain good print quality, only use the recommended paper. In choosing paper other than the recom- mended ones, use the following tables as guidance. Using paper other than that recommended may cause paper jam and other printer problems. Contact your point of purchase for more information. Unacceptable paper Avoid using the following media as they cause paper jams and print quality problem.

  • Page 53: Main Unit

    Tray 2 Tray 1 Only High Capacity Feeder Option (Trays 3, 4, and 5) Paper Source Tray 3 Aug 01 GENICOM LN45 and Intelliprint mL450 User Guide 3-3 Paper Size X (mm) Y(mm) A4 LEF B4 SEF 8.5” x 11” LEF 8.5”...

  • Page 54: Media Sizes Supported

    GENICOM LN45 and Intelliprint mL450 User Guide Media Sizes Supported Paper Source Tray 4 Tray 5 NOTE: 1. Different size papers cannot be mixed and loaded into the same paper source. 2. Duplex printing is possible only when the optional duplexer is installed.

  • Page 55: Media Types Supported

    TRANSPARENCY (A4) PREPUNCHED LETTERHEAD COLORED PREPRINTED BOND CARD STOCK POSTCARD ENVELOPE OTHER Aug 01 GENICOM LN45 and Intelliprint mL450 User Guide 3-5 High Capacity Feeder Option (Trays 3, 4, and 5) Tray Tray Tray Tray Tray Tray Tray Tray Genicom...

  • Page 56: Paper Orientation

    GENICOM LN45 and Intelliprint mL450 User Guide Paper Orientation Paper Orientation Paper Orientation in Trays 1, 2, or 3 Top View of Short Edge Feeds 1 represents duplex printing " 2 represents simplex printing " Paper Orientation in Tray 4...
  • Page 57 Paper Orientation in Tray 5 Top View of Long Edge Feeds 1 represents duplex printing " 2 represents simplex printing " Aug 01 GENICOM LN45 and Intelliprint mL450 User Guide 3-7 Paper Orientation in Tray 5 Genicom Publication No. GEG-99126...

  • Page 58: Paper And Envelope Orientation In The Bypass Feeder

    GENICOM LN45 and Intelliprint mL450 User Guide Paper Orientation Paper and Envelope Orientation in the Bypass Feeder Top View of Short Edge Feeds (SEF) 1 represents duplex printing " 2 represents simplex printing " Top View of Envelope Feeds 1 represents Envelope "...

  • Page 59: Long And Short Edge Duplex Binding In Portrait And Landscape Orientations

    Long and Short Edge Duplex Binding in Portrait and Landscape Orientations Long Edge Duplex Bind in Portrait Orientation Short Edge Duplex Bind in Portrait Orientation Aug 01 GENICOM LN45 and Intelliprint mL450 User Guide 3-9 Paper and Envelope Orientation in the Bypass Feeder Genicom Publication No. GEG-99126...

  • Page 60: Long Edge Duplex Bind In Landscape Orientation

    3-10 GENICOM LN45 and Intelliprint mL450 User Guide Long and Short Edge Duplex Binding in Portrait and Landscape Orientations Long Edge Duplex Bind in Landscape Orientation Short Edge Duplex Bind in Landscape Orientation Publication No. GEG-99126 Genicom Aug 01...

  • Page 61: Paper Paths

    Paper Paths The following illustrations show the paper path through the printer in its standard configuration and also when options are installed. Paper path for standard configuration The paper is pulled out of a paper cassette or the multi bypass feeder.

  • Page 62: Paper Path When Options Are Installed

    3-12 GENICOM LN45 and Intelliprint mL450 User Guide Paper Paths Paper path when options are installed Finisher/Stapler Publication No. GEG-99126 Aug 01 Genicom...

  • Page 63: Paper Delivery

    The following illustration shows the printer with the optional HCF unit, duplexer, and face-up tray installed The paper is pulled out of a paper cassette or the multi bypass feeder. The image is transferred by the photosensitive drum. The toner on the paper is fixed by the fuser.

  • Page 64: Paper Output Tray

    3-14 GENICOM LN45 and Intelliprint mL450 User Guide Paper Delivery Paper output tray The standard output tray enables printouts to emerge facing down. It can store up to about 500 sheets of printed paper. Face-up tray (option) When installed and selected, the face-up tray can store up to about 200 sheets of paper coming out face down.

  • Page 65: Face-Up Tray With The Duplexer (Option)

    GENICOM LN45 and Intelliprint mL450 User Guide 3-15 Face-up tray with the Duplexer (option) Face-up tray with the Duplexer (option) When installed and selected, the face-up tray can store up to about 200 sheets of printouts coming out face down.

  • Page 66: Finisher/Stapler Unit (Option)

    3-16 GENICOM LN45 and Intelliprint mL450 User Guide Adding paper to the 500-sheet paper cassette, Tray 1 or Tray 2 Finisher/Stapler unit (option) Adding paper to the 500-sheet paper cassette, Tray 1 or Tray 2 Pull out desired tray until it stops.
  • Page 67 Prepare a stack of paper. Make sure the tops of the sheets are properly aligned. Gently lift up the length guide, and slide it all the way until it stops. Aug 01 GENICOM LN45 and Intelliprint mL450 User Guide 3-17 Finisher/Stapler unit (option) Genicom...
  • Page 68 3-18 GENICOM LN45 and Intelliprint mL450 User Guide Adding paper to the 500-sheet paper cassette, Tray 1 or Tray 2 While pressing down the gray handle, slide the side guide all the way until stops. Align the four corners of the paper and place the paper in the cassette. The paper should enter easily between the guides.
  • Page 69 Adjust the guide to the paper size correctly otherwise paper may not be transported correctly and may result in paper jam. Align the edges of the paper stack Aug 01 GENICOM LN45 and Intelliprint mL450 User Guide 3-19 Finisher/Stapler unit (option) Genicom Publication No. GEG-99126...

  • Page 70: Adding Paper To The Multi Bypass Feeder

    3-20 GENICOM LN45 and Intelliprint mL450 User Guide Adding paper to the multi bypass feeder Adjust the length guide to the paper length. NOTE: Make sure the guide stopper is locked firmly in the guide hole on the bottom of the cassette.
  • Page 71 If necessary, pull out the extension tray to a length desired for the paper to be loaded. Place paper along the right side of the multi bypass feeder. Push the paper guide until it slightly touches the paper stack. Aug 01 GENICOM LN45 and Intelliprint mL450 User Guide 3-21 Finisher/Stapler unit (option) Genicom Publication No. GEG-99126...

  • Page 72: Adding Paper To The Hcf Unit (2500-Sheet)

    Adding paper to the HCF unit (2500-sheet) Insert the paper stack as far as it can go into the printer. The paper is now ready for use. When the paper is no longer required, remove it and push back the extension tray if necessary.

  • Page 73: Tray 3 (500-Sheet Universal Paper Cassette)

    Pull out Tray 3 until it stops. Prepare a stack of paper. Make sure the tops of the sheets are properly aligned. Aug 01 GENICOM LN45 and Intelliprint mL450 User Guide 3-23 Tray 3 (500-sheet universal paper cassette) Genicom Publication No. GEG-99126...
  • Page 74 3-24 GENICOM LN45 and Intelliprint mL450 User Guide Adding paper to the HCF unit (2500-sheet) Gently lift up the length guide, and slide it all the way until it stops. While pressing down the gray handle, slide the side guide all the way until it stops. If you will use the same paper as before, this step is not required.
  • Page 75 Make sure the paper’s stack height does not exceed the paper limit mark. Adjust the side guide to the paper width. Aug 01 GENICOM LN45 and Intelliprint mL450 User Guide 3-25 Tray 3 (500-sheet universal paper cassette) Genicom Publication No. GEG-99126...
  • Page 76 3-26 GENICOM LN45 and Intelliprint mL450 User Guide Adding paper to the HCF unit (2500-sheet) Align the edges of the paper stack. CAUTION: Adjust the guide to the paper size correctly otherwise paper may not be trans- ported correctly and may result in a paper jam.

  • Page 77: Trays 4 And 5 (A4/Letter Size Paper Compartment)

    Trays 4 and 5 are designated for printing of A4 or letter size paper. The following illustrate how to add paper using Tray 4, the left compartment, as an example. Pull on the latch to open Tray 4. Aug 01 GENICOM LN45 and Intelliprint mL450 User Guide 3-27 Trays 4 and 5 (A4/Letter size paper compartment) Genicom Publication No. GEG-99126...
  • Page 78 3-28 GENICOM LN45 and Intelliprint mL450 User Guide Adding paper to the HCF unit (2500-sheet) Prepare a stack of paper. Make sure the tops of the sheets are properly aligned. Insert paper into the compartment. NOTE: Make sure the paper’s stack height does not exceed the paper limit mark.

  • Page 79: Loading Envelopes Into The Envelope Feeder

    Loading envelopes into the envelope feeder Prepare a stack of envelopes. Make sure the envelopes are not stuck together and all flaps are closed. Aug 01 GENICOM LN45 and Intelliprint mL450 User Guide 3-29 Trays 4 and 5 (A4/Letter size paper compartment) Genicom...
  • Page 80 3-30 GENICOM LN45 and Intelliprint mL450 User Guide Loading envelopes into the envelope feeder While lifting the envelope weight, insert envelopes with the flap-side up and the long edges leading first. Slide the side guide so that it slightly touches the edges of the envelope stack CAUTION: Make sure the envelopes do not exceed the paper limit mark.

  • Page 81: Understanding And Navigating The Control Panel Menus

    “PS Menu” on page 4-12 " “PCL Menu” on page 4-14 " “System Menu” on page 4-17 " “Quality Menu” on page 4-19 " “Functions Menu” on page 4-20 " “Status Menu” on page 4-22 " Aug 01 Genicom Publication No. GEG-99126...

  • Page 82: About This Chapter

    LED Indicators LCD Display The LCD display shows status and error messages that inform you of the current status of the printer, and also displays menus, submenus, and printer settings when you are in the menu system. The display contains two lines of text, each with a maximum of sixteen characters.

  • Page 83: Pushbuttons

    The control panel pushbuttons allow you to access and navigate menus, and also assist you in recovering from printer errors. The table below explains the functions of the eight pushbuttons. PUSHBUTTON START/STOP—Push this button to start or stop the printer, or to exit the menu system. MENU—Push this button to enter the menu system.

  • Page 84: Navigating The Control Panel Menus

    Navigating the Control Panel Menus When you press the MENU button on the control panel, you enter the printer’s menu system. At that point, the first line of the display contains the text “ Menu ”, indicating that you are in the menu system. The second line of the display lists the active menu, which you can change by pressing the NEXT or PREVIOUS button.
  • Page 85 Press the NEXT or PREVIOUS button to increase or decrease the number of copies printed. Press the SELECT button to save this setting. Press the START/STOP button to exit the menu system. Aug 01 GENICOM LN45 and Intelliprint mL450 User Guide 4-5 Menu Interface Menu Copies Paper Menu...

  • Page 86: Menu Structure

    GENICOM LN45 and Intelliprint mL450 User Guide Menu Structure Menu Structure The following figure shows the structure of the control panel main menus and submenus. Paper Menu Copies Default Source Manual Feed Output Tray Media Size/Type Tray 1 Tray 2...

  • Page 87: Paper Menu

    Additional menus and submenus may appear in the printer menu system when other options are installed. Paper Menu The Paper Menu provides access to the printer settings for various paper-handling functions. Use the fol- lowing procedure to enter the paper menu: Press the MENU button on the control panel.
  • Page 88 GENICOM LN45 and Intelliprint mL450 User Guide Paper Menu Media Size/Type This submenu allows Size: Letter LEF you to set the media Type: Plain size and type for the Tray 1 MBF Tray and set the Type: Plain medial type for all Tray 2 other trays.
  • Page 89 Finisher/Stapler is installed. MBF First Aug 01 GENICOM LN45 and Intelliprint mL450 User Guide 4-9 1. Press NEXT or PREVIOUS to toggle between ON and OFF. 2. Press SELECT to save this setting. 1. Press NEXT or PREVIOUS to toggle between ON and OFF.

  • Page 90: Interface Menu

    GENICOM LN45 and Intelliprint mL450 User Guide Interface Menu Interface Menu The Interface Menu provides access to the printer interface settings. Use the following procedure to enter the interface menu: Press the MENU button on the control panel. Press the NEXT button until the text “ Interface Menu ” is shown on the second line of the display.
  • Page 91 Format: Mode: Bidirectional Delay Out Close: Aug 01 GENICOM LN45 and Intelliprint mL450 User Guide 4-11 Interpreter: 1. Press NEXT or PREVIOUS to scroll through the Auto Switch INTERPRETER, FORMAT, MODE, and DELAY OUT CLOSE submenus. PostScript 3 2. Press SELECT to choose a submenu.

  • Page 92: Ps Menu

    4-12 GENICOM LN45 and Intelliprint mL450 User Guide PS Menu Network 1 Setup Interpreter: This submenu allows you Auto Switch to set up the Network interface. Format: Network Channel: Netware Network Address: IP Address: (user-specified) Subnet Mask: (user-specified) Default Router:...
  • Page 93 Aug 01 GENICOM LN45 and Intelliprint mL450 User Guide 4-13 Available Settings Procedure for Changing Settings 1. Press NEXT or PREVIOUS to toggle between ON (print) and OFF (do not print).

  • Page 94: Pcl Menu

    4-14 GENICOM LN45 and Intelliprint mL450 User Guide PCL Menu PCL Menu The PCL Menu provides access to the PCL settings. Use the following procedure to enter the PCL menu: Press the MENU button on the control panel. Press the NEXT button until the text “ PCL Menu ” is shown on the second line of the display.
  • Page 95 Aug 01 GENICOM LN45 and Intelliprint mL450 User Guide 4-15 5 - 128 CR = CR CR = CR/LF LF = LF LF = CR/LF...
  • Page 96 4-16 GENICOM LN45 and Intelliprint mL450 User Guide PCL Menu Print Area Normal This submenu allows you to set the print area. Parameter Values Paper Source: Paper Size: Executive Publication No. GEG-99126 Normal Expanded Paper Source: Paper Size: Executive, Letter,...

  • Page 97: System Menu

    This setting applies to both PCL and PostScript print jobs. Aug 01 GENICOM LN45 and Intelliprint mL450 User Guide 4-17 Default Setting Available Settings U.S. U.S. Non-U.S.
  • Page 98 4-18 GENICOM LN45 and Intelliprint mL450 User Guide System Menu Job Timeout This submenu allows you to increase or decrease the time limit (in seconds) for PostScript jobs. A 0 setting indicates no timeout. This setting applies only to PostScript jobs.

  • Page 99: Quality Menu

    This submenu allows you to specify the print density. 1 represents the lightest print density, while 7 represents the darkest print density. Aug 01 GENICOM LN45 and Intelliprint mL450 User Guide 4-19 Quality Menu Default Setting Available Settings 600 dpi 300 dpi...

  • Page 100: Functions Menu

    Consult the documentation that came with your FLASH DIMM for detailed installation and usage instructions. The FLASH Menu provides access to the printer settings that are related to the optional FLASH DIMM. Use the following procedure to enter the FLASH Menu: Press the MENU button on the control panel.

  • Page 101: Disk Menu

    The Disk Menu provides access to the printer settings that are related to the optional Hard Disk. Use the fol- lowing procedure to enter the Disk Menu: Press the MENU button on the control panel.

  • Page 102: Status Menu

    Status Menu In addition to the main menus listed above, the printer also provides a status menu that allows you to view the current settings for the input and output trays and the toner cartridge. Use the following procedure to enter the Status Menu: Press the STATUS button on the control panel.
  • Page 103 Toner Press SELECT to view the status of the toner cartridge. Aug 01 GENICOM LN45 and Intelliprint mL450 User Guide 4-23 1. Press NEXT or PREVIOUS to scroll through the media size, media type, and level settings for Tray 2.
  • Page 104 4-24 GENICOM LN45 and Intelliprint mL450 User Guide Status Menu Publication No. GEG-99126 Genicom Aug 01...

  • Page 105: Printer Consumables

    “Replacing the Feed Rollers” on page 5-20 " “Cleaning” on page 5-26 " “Daily Maintenance” on page 5-28 " “Preparing the Printer for a Period of Extended Non-Use” on page 5-28 " “Relocating the Printer” on page 5-30 " Aug 01 Genicom...

  • Page 106: About This Chapter

    Do not carry out the procedure in a brightly lit location, and complete the installation procedure as " quickly as possible (within about 5 minutes). When the EP cartridge is removed from the printer, immediately put it back to its original packing or " wrap it with a thick lint-free cloth.

  • Page 107: Replacing The Ep Cartridge (For Standard Configuration)

    When there is no more toner or the drum must be replaced, an error message appears and the printer stops. Follow the steps described in the following sections to replace the EP cartridge with a new one. Be sure to use only the designated EP cartridge.
  • Page 108 GENICOM LN45 and Intelliprint mL450 User Guide Replacing the EP Cartridge Open the front cover as indicated. WARNING: Never touch the fuser area where a label indicating high temperature is located (such as that shown below), or else burns may result.
  • Page 109 Hold the EP cartridge horizontally and gently shake it 5 to 6 times to evenly distribute the toner inside. CAUTION: Uneven toner distribution may degrade print quality. If the toner has not been properly freed by shaking the cartridge, a noise may be heard when turning on the printer and the EP cartridge may be damaged.
  • Page 110 Replacing the EP Cartridge Open the front cover as indicated. While holding the orange handle with one hand, gently push the cartridge all the way into the printer. NOTE: Do not touch any parts inside the printer. Make sure the cartridge is seated properly.
  • Page 111 Close the front cover and the upper left cover. The upper left cover can be closed only when the EP cartridge is inside the printer. If you have not installed the EP cartridge, do not close the upper left cover by force. When clos- ing the upper left cover, do not use the latch on the cover.

  • Page 112: Replacing The Ep Cartridge (When Options Are Installed)

    GENICOM LN45 and Intelliprint mL450 User Guide Replacing the EP Cartridge Replacing the EP cartridge (when options are installed) If the duplex printing unit is installed, pull on its latch to open it. Hold the latch and open the upper left cover.
  • Page 113 Be careful about the toner falling out, then wrap the used EP cartridge in its original packing and dispose it properly. Never dispose of it by burning. Aug 01 GENICOM LN45 and Intelliprint mL450 User Guide 5-9 Replacing the EP cartridge (when options are installed) Genicom...
  • Page 114 Hold the EP cartridge horizontally and gently shake it 5 to 6 times to evenly distribute the toner inside. CAUTION: Uneven toner distribution may degrade print quality. If the toner has not been properly freed by shaking the cartridge, a noise may be heard when turning on the printer and the EP cartridge may be damaged.
  • Page 115 WARNING: Never touch the fuser area where a label indicating high temperature is located (such as that shown below), or else burns may result While holding the orange handle with one hand, gently push the cartridge all the way into the printer. NOTE: Do not touch any parts inside the printer.
  • Page 116 Close the front cover and the upper left cover. NOTE: The upper left cover can be closed only when the EP cartridge is inside the printer. If you have not installed the EP cartridge, do not close the upper left cover by force. When closing the upper left cover, do not use the latch on the cover.

  • Page 117: Replacing The Fuser

    The fuser becomes very hot during operation. Never touch the fuser area where a label indicating high temperature is located (such as that shown below), or else burns may result. Before replacing the fuser, turn the printer off and wait at least 40 minutes before replacing it.
  • Page 118 5-14 GENICOM LN45 and Intelliprint mL450 User Guide Replacing the Fuser Open the upper left cover. Open the front cover. Publication No. GEG-99126 Genicom Aug 01...
  • Page 119 Loosen the two locking screws indicated. (You cannot remove them completely.) Hold the two rings indicated and pull out the fuser. Dispose of the fuser Aug 01 GENICOM LN45 and Intelliprint mL450 User Guide 5-15 Replacing the EP cartridge (when options are installed) Genicom...
  • Page 120 5-16 GENICOM LN45 and Intelliprint mL450 User Guide Replacing the Fuser Prepare a new fuser. While holding the two rings of the new fuser, push into the printer as indicated. Tighten the two locking screws. Publication No. GEG-99126 Genicom Aug 01...
  • Page 121 Using a coin or a flat head screwdriver with a wide blade, turning in a counter-clockwise direction, loosen the two metal fuser shipping screws. Aug 01 GENICOM LN45 and Intelliprint mL450 User Guide 5-17 Replacing the EP cartridge (when options are installed) Genicom...
  • Page 122 5-18 GENICOM LN45 and Intelliprint mL450 User Guide Replacing the Fuser Completely remove and discard the two metal fuser shipping screws Close the front cover and then the upper left cover. Publication No. GEG-99126 Genicom Aug 01...

  • Page 123: Replacing The Transfer Roller

    Open the upper left cover. Lift up the handles to unlock the transfer roller. Aug 01 GENICOM LN45 and Intelliprint mL450 User Guide 5-19 Replacing the EP cartridge (when options are installed) Genicom Publication No. GEG-99126...

  • Page 124: Replacing The Feed Rollers

    5-20 GENICOM LN45 and Intelliprint mL450 User Guide Replacing the Feed Rollers Remove the transfer roller. Insert a new transfer roller and press down to hold the roller in place. Push the handles to lock the transfer roller in place.
  • Page 125 While pressing the white tab, remove the lower feed roller. NOTE: Be sure not to remove the coupling behind the feed roller. Aug 01 GENICOM LN45 and Intelliprint mL450 User Guide 5-21 Replacing the EP cartridge (when options are installed) Genicom Publication No. GEG-99126...
  • Page 126 5-22 GENICOM LN45 and Intelliprint mL450 User Guide Replacing the Feed Rollers Flip down the cover and remove the upper two rollers with the same steps described earlier. While pressing the white tab, remove the upper two rollers. Insert a new upper feed rollers.

  • Page 127: Tray 5 (Hcf Unit)

    Inset a new lower feed roller. Tray 5 (HCF Unit) Remove the Tray 3. Pull out the Tray 5. Aug 01 GENICOM LN45 and Intelliprint mL450 User Guide 5-23 Genicom Tray 5 (HCF Unit) Publication No. GEG-99126...
  • Page 128 5-24 GENICOM LN45 and Intelliprint mL450 User Guide Replacing the Feed Rollers Pull the roller cover towards you. While pressing the white tab, remove the three feed rollers NOTE: Be sure not to remove the coupling behind the feed roller.

  • Page 129: Tray 4 (Hcf Unit)

    While pressing the white tab, remove the three feed rollers. NOTE: Be sure not to remove the coupling behind the feed roller. Aug 01 GENICOM LN45 and Intelliprint mL450 User Guide 5-25 Genicom Tray 4 (HCF Unit) Publication No. GEG-99126...

  • Page 130: Cleaning

    Insert three new feed rollers. Push back Tray 4. Cleaning In order to keep your printer in optimum working condition, clean the exterior and interior of the printer as described below. WARNING: Before cleaning the printer or performing any other maintenance tasks, be sure to turn off the printer and disconnect the power cord from the AC outlet.

  • Page 131: Clean The Exterior Of The Printer

    Clean the exterior of the printer Clean the exterior of the printer about once a month. Use a soft cloth slightly moistened with water. For stubborn stains, soak the cloth in a mild detergent solution before cleaning. Finish by wiping the printer with a soft, dry cloth.

  • Page 132: Daily Maintenance

    GENICOM LN45 and Intelliprint mL450 User Guide Daily Maintenance Daily Maintenance At the end of the day, turn off the printer by setting the power switch to [0]. If any error message or status code appears, see ”Chapter 6 Preparing the Printer for a Period of Extended Non-Use If the printer will not be used for one week or more, perform the following steps.
  • Page 133 If any error message or status code appears, see properly. Unplug the power cord from the AC outlet. Aug 01 GENICOM LN45 and Intelliprint mL450 User Guide 5-29 Check the interior of the printer ”Chapter 6 Troubleshooting” Genicom and turn off the printer...

  • Page 134: Relocating The Printer

    To carry the printer, grasp the four bottom corners from the right and left sides, not from the front (where the control panel is located) and back sides. Never try to lift the printer while holding any part other than the bottom corners.
  • Page 135 Remove any options such as the duplex printing unit before moving the printer. For instructions on how to remove the options, see the appropriate section. To transport the printer over long distance, put the printer in its original shipping carton and other packing materials.
  • Page 136 5-32 GENICOM LN45 and Intelliprint mL450 User Guide Relocating the Printer Remove any paper from the multi bypass feeder as well as all the paper cassettes.Store the paper in a location that is not humid and dusty. For more information, see latory Compliances”.
  • Page 137 Remove the EP cartridge inside the printer. If the printer is moved with the cartridge inside, toner may spill out and soil the printer. NOTE: Replace the EP cartridge in its original packing material, or wrap it in a thick lint-free cloth.
  • Page 138 5-34 GENICOM LN45 and Intelliprint mL450 User Guide Relocating the Printer Publication No. GEG-99126 Aug 01 Genicom...

  • Page 139: Troubleshooting

    Troubleshooting In this Chapter . . . “About this Chapter” on page 6-2 “Solving Printer Power-on Problems” on page 6-2 “Solving Print Quality Problems” on page 6-3 “Clearing Paper Jams” on page 6-7 “Control Panel LCD Messages” on page 6-18 “Ethernet Network Interface Troubleshooting”...

  • Page 140: Solving Printer Power-On Problems

    This section describes problems that can occur when starting up the printer. If the trouble persists after per- forming the checks listed below, turn the printer off [ O ], disconnect the power cord from the AC outlet, and see ”Appendix E GENICOM Customer Support and Part Numbers”...

  • Page 141: Solving Print Quality Problems

    This section describes quality problems during printing. Go through the list below to find the conditon that most closely resembles the problem and follow the recommended action. If the trouble persists after per- forming the checks listed below, turn the printer off [ O ], disconnect the power cord from the AC outlet, and see ”Appendix E GENICOM Customer Support and Part Numbers”...
  • Page 142 GENICOM LN45 and Intelliprint mL450 User Guide Solving Print Quality Problems DESCRIPTION Black dots Vertical black streaks Repetitive defects. Character voids Publication No. GEG-99126 POSSIBLE CAUSE Print media is outside Use recommended print media. See recommended specification. ”Chapter 5 Printer Consumables, Cleaning and Maintenance”...
  • Page 143 DESCRIPTION Toner smears when rubbed Black page Blank page Partial blanks Aug 01 GENICOM LN45 and Intelliprint mL450 User Guide 6-5 POSSIBLE CAUSE Print media is moist Remove moist media and load new dry media. See See Consumables, Cleaning and Maintenance”...
  • Page 144 GENICOM LN45 and Intelliprint mL450 User Guide Solving Print Quality Problems DESCRIPTION Creased paper Plotted print Vertical blanks Publication No. GEG-99126 POSSIBLE CAUSE Print media is outside Use recommended print media. See recommended specifications ”Chapter 5 Printer Consumables, Cleaning and Maintenance”...

  • Page 145: Clearing Paper Jams

    Blurred print Bold print appears shaded Clearing Paper Jams This section provide information for removing paper jams from paper path areas of your printer and paper handling options. Clearing Paper Jams from Area A If the duplexer is installed, pull on the latch indicated to open the unit...
  • Page 146 GENICOM LN45 and Intelliprint mL450 User Guide Clearing Paper Jams Pull on the latch to open the upper left cover. If the optional face up tray is installed instead of the duplexer, lift to unhook and remove the face up tray.
  • Page 147 WARNING: Never touch the fuser area where a label indicating high temperature is located (such as that shown below), or else burns may result. Aug 01 GENICOM LN45 and Intelliprint mL450 User Guide 6-9 Clearing Paper Jams from Area A Genicom...
  • Page 148 6-10 GENICOM LN45 and Intelliprint mL450 User Guide Clearing Paper Jams If the paper is jammed at the indicated location, pull it out in the direction of the arrow. Open the cover inside the duplexer. Remove any paper jam found by pulling out the paper in the direction of the arrow as shown.
  • Page 149 When closing the duplexer, do not use the latch on the cover. Instead, follow the instruction label on the cover and push the recommended location. Aug 01 GENICOM LN45 and Intelliprint mL450 User Guide 6-11 Clearing Paper Jams from Area A Genicom...

  • Page 150: Clearing Paper Jams From Area B

    6-12 GENICOM LN45 and Intelliprint mL450 User Guide Clearing Paper Jams Close the duplexer or reinsert the face-up tray as appropriate. Clearing Paper Jams from Area B Pull on the latch to open the cover to Area B Remove any paper jam found Publication No.

  • Page 151: Clearing Paper Jams From Area C

    If the paper is jammed at Area B, pull it out in the direction of the arrow as shown. If no paper jam is found consult the LCD display of the control panel for information about a possible jam in a paper tray. Aug 01 GENICOM LN45 and Intelliprint mL450 User Guide 6-13 Clearing Paper Jams from Area C Genicom Publication No. GEG-99126...

  • Page 152: Clearing Paper Jams From Area E

    6-14 GENICOM LN45 and Intelliprint mL450 User Guide Clearing Paper Jams Clearing Paper Jams from Area E Lift the handle of the Stapler/Stacker docking cover and remove any jammed paper found. Clearing Paper Jams from Area F Open the cover of the Stacker/Stapler’s paper horizontal transport and remove any jammed paper found.

  • Page 153: Clearing Paper Jams From Area H

    Pull out Tray 3 of the HCF unit. Check the paper feed area and carefully pull out any jammed paper found there. Carefully close Tray 3. Aug 01 GENICOM LN45 and Intelliprint mL450 User Guide 6-15 Clearing Paper Jams from Area H Genicom Publication No. GEG-99126...
  • Page 154 6-16 GENICOM LN45 and Intelliprint mL450 User Guide Clearing Paper Jams Pull out Trays 4 and 5. Check the paper feed area of Tray 5 and remove any jammed paper found Carefully close Trays 4 and 5 Publication No. GEG-99126...

  • Page 155: Clearing Paper Jams From The Multi-Bypass Feeder (Mbf)

    Remove all the paper and load the stack again. Clearing Paper Jams from the Envelope Feeder Remove the envelope feeder. Aug 01 GENICOM LN45 and Intelliprint mL450 User Guide 6-17 Clearing Paper Jams from the Multi-Bypass Feeder (MBF) Genicom Publication No. GEG-99126...

  • Page 156: Control Panel Lcd Messages

    LCD messages involving troubleshooting are classified into nine numeric code classes (1 through 9) and an additional alphanumeric class. These code classes have no significance to you as a user of this printer. These class codes are designed specifically for assisting service and repair personnel. When reporting problems make note of the error message by code class.

  • Page 157: Code Class 1 - Lcd Messages

    1-3 PAPER JAM 1-3 TRAY ERROR 1-4 DRUM MOTOR 1-4 TRAY ERROR 1-5 TRAY ERROR 1-6 PAPER JAM Aug 01 GENICOM LN45 and Intelliprint mL450 User Guide 6-19 LCD MESSAGE CAUSE OF (LINE 2) ERROR MESSAGE Main Motor Rotation CALL SERVICE...

  • Page 158: Code Class 2 - Lcd Messages

    6-20 GENICOM LN45 and Intelliprint mL450 User Guide Control Panel LCD Messages Code Class 2 LCD MESSAGE (LINE 1) 2-2 FEED ERROR 2-3 FEED ERROR 2-7 DUPLEX COMM 2-8 DUPLEX ERROR Code Class 3 LCD MESSAGE (LINE 1) 3-1 NO CARTRIDGE...

  • Page 159: Code Class 4 - Lcd Messages

    4-3 FUSER ERROR 4-3 IRREG. PAPER 4-3 PAPER JAM 4-4 FUSER ERROR 4-4 IRREG. PAPER Aug 01 GENICOM LN45 and Intelliprint mL450 User Guide 6-21 LCD MESSAGE CAUSE OF (LINE 2) ERROR MESSAGE Tray 4 paper misfeed AREA C/TRAY 4...
  • Page 160 6-22 GENICOM LN45 and Intelliprint mL450 User Guide Control Panel LCD Messages 4-5 FUSER ERROR 4-5 IRREG. PAPER 4-5 PAPER JAM 4-6 PAPER JAM 4-9 FUSER ERROR 4-11 FINISH JAM 4-12 FINISH JAM 4-13 FINISH JAM 4-16 FINISH JAM 4-21 FINISH JAM...
  • Page 161 4-46 FINISH JAM 4-51 FINISH JAM 4-52 FINISH JAM 4-56 FINISH JAM 4-61 FINISH JAM 4-66 FINISH JAM Aug 01 GENICOM LN45 and Intelliprint mL450 User Guide 6-23 Remaining paper CLEAR AREA F detected on TRANSPORT exit sensor Paper does not pass...

  • Page 162: Code Class 5 - Lcd Messages

    6-24 GENICOM LN45 and Intelliprint mL450 User Guide Control Panel LCD Messages Code Class 5 LCD MESSAGE (LINE 1) 5-0 FEED ERROR 5-1 COVER OPEN 5-1 COVER OPEN 5-1 FEED ERROR 5-2 COVER OPEN 5-2 FEED ERROR 5-3 FEED ERROR...
  • Page 163 6-3 NVRAM ERROR 6-4 NVRAM ERROR 6-5 MCU ERROR 6-7 FIN ERROR 6-8 FIN ERROR Aug 01 GENICOM LN45 and Intelliprint mL450 User Guide 6-25 Finisher Stapler head CALL SERVICE home sensor failure (see note 3) Finisher Stapler front CALL SERVICE...
  • Page 164 6-26 GENICOM LN45 and Intelliprint mL450 User Guide Control Panel LCD Messages Code Class 7 LCD MESSAGE (LINE 1) 7-1 COVER OPEN 7-2 COVER OPEN 7-3 DUPLEX OPEN 7-3 FIN EXIT SW 7-3 HCF ERROR 7-4 HCF ERROR 7-7 HCF ERROR...
  • Page 165 8-4 TONER CART 8-4 FEED ERROR 8-5 TONER CART 8-5 FEED ERROR 8-6 FEED ERROR 8-6 PAPER JAM Aug 01 GENICOM LN45 and Intelliprint mL450 User Guide 6-27 LCD MESSAGE CAUSE OF (LINE 2) ERROR MESSAGE Remaining paper CHECK ENVELOPE...
  • Page 166 6-28 GENICOM LN45 and Intelliprint mL450 User Guide Control Panel LCD Messages Code Class 9 LCD MESSAGE (LINE 1) 9-1 FEED ERROR 9-2 FEED ERROR 9-3 FEED ERROR Publication No. GEG-99126 LCD MESSAGE CAUSE OF (LINE 2) ERROR MESSAGE ENV OUT sensor...

  • Page 167: Alphanumeric Code Class - Lcd Messages

    STACKER TOP FULL STAPLE CARTRIDGE STAPLES LOW TONER LOW PUNCH WASTE FULL NO PUNCH WASTE Aug 01 GENICOM LN45 and Intelliprint mL450 User Guide 6-29 LCD MESSAGE CAUSE OF (LINE 2) ERROR MESSAGE P/R Drum end of life N/A (WARNING...

  • Page 168: Ethernet Network Interface Troubleshooting

    These errors are only treated as faults when there is no alternative action to take. Your printer may be configured so that the problem is easily avoided. When the problem cannot be avoided, the described faults will be displayed.

  • Page 169: Printing Problems

    The network interface and host are in the same IP network Aug 01 GENICOM LN45 and Intelliprint mL450 User Guide 6-31 Explanation To test a non-PostScript printer use the Test Port 1 Count 100 command. This command will send 100 lines of test data to the printer.

  • Page 170: Dhcp Troubleshooting

    6-32 GENICOM LN45 and Intelliprint mL450 User Guide Ethernet Network Interface Troubleshooting DHCP Troubleshooting Area to Check DHCP is enabled on the network interface. Make sure the DHCP server is operational. Did the network interface get its IP address from the DHCP server?

  • Page 171: Bitmap Graphics

    Status of the unit when the problem occurred (please try to include information on user and network activity at the time of the problem). Aug 01 GENICOM LN45 and Intelliprint mL450 User Guide 6-33 Explanation Issue the Show Service Characteristics command. If the service rating is zero, the parallel port is in use.
  • Page 172 6-34 GENICOM LN45 and Intelliprint mL450 User Guide Ethernet Network Interface Troubleshooting Publication No. GEG-99126 Aug 01 Genicom...

  • Page 173: Installing Dram Memory Dimms

    In this Chapter . . . “About this Chapter” on page 7-2 " “Installing DRAM Memory DIMMS” on page 7-2 " “Installing a FLASH DIMM Module” on page 7-5 " “Using the Power-On Files Feature” on page 7-7 " Aug 01 Genicom Publication No. GEG-99126...

  • Page 174: Installing Dram Memory Dimms

    Downloading software to the FLASH DIMM module is also discussed in this chapter. Installing DRAM Memory DIMMS Ensure that the printer power switch is set to the OFF [ O ] position. Disconnect the power cord from the wall outlet.
  • Page 175 Turn thumbscrews on controller assembly counterclockwise until loose and gently pull controller assembly towards you to remove from printer. Carefully insert a DRAM DIMM which is compatible with your printer into any available DRAM DIMM slot as shown below. When properly seated, gently push down on the DIMM until the white braces close and snap onto the ends of the DIMM.
  • Page 176 GENICOM LN45 and Intelliprint mL450 User Guide Installing DRAM Memory DIMMS Reinstall the controller assembly. Once firmly in place, push and hand tighten the thumbscrews in a clockwise direction. Connect the power cord to the wall outlet. Turn the printer power switch to the ON [ I ] position.

  • Page 177: Installing A Flash Dimm Module

    Installing a FLASH DIMM Module Ensure that the printer power switch is set to the OFF [ O ] position. Disconnect the power cord from the wall outlet. Turn thumbscrews on controller assembly counterclockwise until loose and gently pull controller assembly towards you to remove from printer.
  • Page 178 GENICOM LN45 and Intelliprint mL450 User Guide Installing a FLASH DIMM Module Carefully insert a FLASH DIMM module in FLASH DIMM slot as shown below. When properly seated, gently push down on the DIMM until the white braces close onto the ends of the DIMM.

  • Page 179: Using The Power-On Files Feature

    Using the Power-On Files Feature Power-on Files Defined If an optional FLASH DIMM or hard disk drive is installed in your printer, your printer has the capability of storing additional power-on files which can be read and interpreted at power-on. See page 4-20 “DISK Menu”...
  • Page 180 GENICOM LN45 and Intelliprint mL450 User Guide Using the Power-On Files Feature NOTE: Contact the technical support team at your point of purchase for additional information regarding loading and using power-on files. Publication No. GEG-99126 Genicom Aug 01...

  • Page 181: General Information

    General Information “About this Appendix” on page A-2 " “Specifications” on page A-2 " “Printable Area” on page A-3 " Aug 01 Genicom Publication No. GEG-99126...

  • Page 182: About This Appendix

    GENICOM LN45 and Intelliprint mL450 User Guide Specifications About this Appendix Provides printer specifications and information on the EP cartridge and the printable area of a page. Specifications Main Unit Printing principle Print speed Warm-up time Resolution Paper capacity Paper sizes...

  • Page 183: Printable Area

    When the host computer issues the command for wide printing, then the printable area is from edge to edge on all sides of a sheet of paper. However, depending on the paper type, edge-to-edge printing may not be possible. Aug 01 GENICOM LN45 and Intelliprint mL450 User Guide Genicom Normal printing Publication No. GEG-99126...
  • Page 184 GENICOM LN45 and Intelliprint mL450 User Guide Printable Area Publication No. GEG-99126 Aug 01 Genicom...

  • Page 185: Regulatory Compliances

    Safety Notes and Regulatory Compliances In this Chapter . . . “About this Appendix” on page B-2 " “Safety Notes” on page B-2 " “Regulatory Compliances” on page B-4 " Aug 01 Genicom Publication No. GEG-99126...

  • Page 186: Safety Notes

    GENICOM LN45 and Intelliprint mL450 Installation Guide Safety Notes About this Appendix Describes cautions to take when installing, transporting, or operating the printer. Also includes applicable regulatory compliances of your printer. Safety Notes WARNING: Two power specifications are listed below. The specifications that apply to your machine depend on your machine configuration.

  • Page 187: Location And Environment Precautions

    Do not expose the machine to direct sunlight. Exposure to direct sunlight can adversely affect the " machine's performance. For information on how to secure the printer against movement or tipping in case of an earthquake, " please contact your point of purchase.

  • Page 188: Paper Jam Precautions

    GENICOM LN45 and Intelliprint mL450 Installation Guide Regulatory Compliances If debris (metal or liquid) migrates into the machine, switch off and unplug the machine. Contact your " point of purchase. Operating a debris-contaminated machine can cause a fire or shock hazard.

  • Page 189: Class 1 Laser Device And Cdrh Compliance

    * This regulation applies only to Japan. This printer is certified as a Class 1 laser product under the U.S. Department of Health and Human Services (DHHS) Radiation Performance Standard according to the Radiation Control for Health and Safety Act of 1968.
  • Page 190 GENICOM LN45 and Intelliprint mL450 Installation Guide Regulatory Compliances Reorientate the TV and/or radio antennas and cables until the interference stops. For an outdoor " antenna, ask your local electrician for support. Use coaxial cable antennas. " Publication No. GEG-99126...

  • Page 191: Printing Font Summaries

    In this Chapter . . . “About this Appendix” on page C-2 " “Printing a Font Summary” on page C-2 " “PostScript Font Summary” on page C-3 " “PCL Font Summary” on page C-7 " Aug 01 Genicom Publication No. GEG-99126...

  • Page 192: Printing A Font Summary

    Printing a Font Summary Your printer has the capability of printing summaries of all installed PCL or PostScript fonts. To print a Font Summary, follow these steps: From the Ready status, press MENU, the control panel display will read:...

  • Page 193: Postscript Font Summary

    GENICOM LN45 and Intelliprint mL450 User Guide PostScript Font Summary Aug 01 Publication No. GEG-99126 Genicom...
  • Page 194 GENICOM LN45 and Intelliprint mL450 User Guide PostScript Font Summary PostScript Font Summary (contíd) Publication No. GEG-99126 Aug 01 Genicom...

  • Page 195: Postscript Font Summary (Cont'd)

    GENICOM LN45 and Intelliprint mL450 User Guide PostScript Font Summary (cont’d) PostScript Font Summary (cont’d) Aug 01 Publication No. GEG-99126 Genicom...
  • Page 196 GENICOM LN45 and Intelliprint mL450 User Guide PostScript Font Summary PostScript Font Summary (contíd) Publication No. GEG-99126 Aug 01 Genicom...

  • Page 197: Pcl Font Summary

    GENICOM LN45 and Intelliprint mL450 User Guide PostScript Font Summary (cont’d) PCL Font Summary Aug 01 Publication No. GEG-99126 Genicom...

  • Page 198: Pcl Font Summary (Cont'd)

    GENICOM LN45 and Intelliprint mL450 User Guide PCL Font Summary PCL Font Summary (cont’d) Publication No. GEG-99126 Aug 01 Genicom...

  • Page 199: Server Commands

    Frequently Used Ethernet Commands In this Chapter . . . • “About this Appendix” on page D-2 • “Server Commands” on page D-3 • “Protocol Commands” on page D-6 Aug 2001 Genicom Publication No. GEG-99126...
  • Page 200 GENICOM LN45 and Intelliprint mL450 User Guide About this Appendix This appendix lists some of the most frequently-used commands of the information about the command set, including additional options, can be found in the Ethernet Network Interface Manual on the Electronic Library CD-ROM.

  • Page 201: Server Commands

    DEFINE SERVER NAME “newname” DEFINE SERVER NETWARE LOADHOST server DEFINE SERVER PRIVILEGED PASSWORD DEFINE SERVER RARP {EN|DIS} Aug 2001 GENICOM LN45 and Intelliprint mL450 User Guide Frequently-used Server Commands Option(s) Description Enables or disables querying for a BOOTP host at system boot time.
  • Page 202 GENICOM LN45 and Intelliprint mL450 User Guide Command DEFINE SERVER SOFTWARE “filename” DEFINE SERVER SUBNET MASK ipmask HELP option DEFINE SERVICE “name” PORT num DEFINE SERVICE “name” option DEFINE SERVICE “name” option Publication No. GEG-99126 Frequently-used Server Commands Option(s) Description Specifies the name or path (TCP) of the software download file.
  • Page 203 {SHOW|MONITOR} QUEUE {SHOW|MONITOR} SERVER {SHOW|MONITOR} SERVICE option ZERO COUNTERS option Aug 2001 GENICOM LN45 and Intelliprint mL450 User Guide Frequently-used Server Commands Option(s) Description TCPPORT string Specifies a service. Enter a socket number (4000 to 4999) or the word none.

  • Page 204: Protocol Commands

    GENICOM LN45 and Intelliprint mL450 User Guide Protocol Commands In the following table, PROTO Command DEFINE PROTO APPLETALK option DEFINE PROTO IP option DEFINE PROTO LAT option DEFINE PROTO NETWARE option DEFINE PROTO NETWARE ENCAPSULATION option {EN|DIS} Publication No. GEG-99126...
  • Page 205 Command DEFINE PROTO NETWARE LOADHOST server PURGE PROTO NETWARE ACCESS option {SHOW|MONITOR} protocolname Aug 2001 GENICOM LN45 and Intelliprint mL450 User Guide Protocol Commands Option(s) Description Same as see “DEFINE SERVER NETWARE LOADHOST server” on page D-3. Removes all entries from the NetWare access list.
  • Page 206 GENICOM LN45 and Intelliprint mL450 User Guide Publication No. GEG-99126 Aug 2001 Genicom...
  • Page 207 In this Chapter . . . “About this Appendix” on page E-2 " “Sources of Support” on page E-2 " “GENICOM World-wide Offices” on page E-3 " “GENICOM LN45 and Intelliprint mL450 Part Numbers” on page E-5 " Aug 01 Genicom Publication No. GEG-99126...

  • Page 208: About This Appendix

    The GENICOM server provides access to technical reports, new product announcements, a trade show schedule, and other general information about GENICOM. You can access the GENICOM world wide web server via any one of the many world-wide web browsers available to Internet users. The GENICOM home page is at http://www.genicom.com.

  • Page 209: Genicom World-Wide Offices

    GENICOM Sales - (800) 436-4266 " GENICOM Service - (888) 367-3772 " GENICOM Parts - (800) 436-4266 x 2 x 3, Parts ID: (800) 436-4266 x 4 " GENICOM Supplies - (800) 436-4266 x 2 x 1 " GENICOM World-wide Offices...
  • Page 210 GENICOM LN45 and Intelliprint mL450 User Guide GENICOM World-wide Offices GENICOM Germany GENICOM Italy GENICOM The Netherlands GENICOM Singapore GENICOM U.K. Publication No. GEG-99126 GENICOM GmbH Robert-Bosch-StraBe 52 63225 Langen/Germany Telephone: 49 0 61 03/706 59-0 Fax: 49 0 61 03/706 59-59...

  • Page 211: Genicom Ln45 And Intelliprint Ml450 Part Numbers

    GENICOM LN45 and Intelliprint mL450 Part Numbers Printers GENICOM Part Number ML450N-CA ML450N-CC ML450N-MA ML450A-CA ML450A-CC LN45N-CA LN45N-CC LN45A-CA LN45A-CC Paper Handling and Other Options GENICOM Part Number ML450F-TL ML450F-SA ML450F-SB ML450F-DA ML450F-TE ML450F-TF ML450-TR ML450-TW Aug 01 GENICOM LN45 and Intelliprint mL450 User Guide...

  • Page 212: Network Interfaces

    GENICOM LN45 and Intelliprint mL450 User Guide GENICOM LN45 and Intelliprint mL450 Part Numbers Network Interfaces GENICOM Part Number MLXXXN-CX MLXXXF-SI ML450N-CS ML450N-TS ML450N-CI ML450N-TI ML450N-EI DRAM, FLASH DIMM, Barcode and Hard Disk Drive Options GENICOM Part Number MLXXXM-64 MLXXXM-128...

  • Page 213: User Publications

    GENICOM Part Number ML450X-AA ML450X-MA ML450X-AG ML450X-BG ML450X-AS Aug 01 GENICOM LN45 and Intelliprint mL450 User Guide Description GENICOM Intelliprint mL450 Electronic Library Contents include but are not limited to the following documents: • GENICOM LN45 and Intelliprint mL450 User Guide •...
  • Page 214 GENICOM LN45 and Intelliprint mL450 User Guide GENICOM LN45 and Intelliprint mL450 Part Numbers Publication No. GEG-99126 Aug 01 Genicom...

This manual is also suitable for:

Ln45

Table of Contents
