SET MODES

D Microphone simple mode
Microphone simple mode is used to assign the essential opera-
tions to the four switches (S1 to S4) on the remote control unit.
• mS .Sm
S1
Selects the Call channel.
S2 Turns the monitor function ON or OFF.
S3 Selects memory channel 0.
S4 Selects memory channel 1.
• mS .n1 (default)
S1 Toggles the VFO mode and the memory mode.
S2 Selects the Call channel.
S3
Frequency or memory channel "UP."
S4 Frequency or memory channel "DOWN."
• mS .n2
S1 Toggles the VFO mode and the memory mode.
S2 Turns the monitor function ON or OFF.
S3
Frequency or memory channel "UP."
S4
Frequency or memory channel "DOWN."
• User remote control unit
The below circuit is for reference only.
2.7kW 6.8kW 15kW
S1 S2 S3
47
to the [SP] jack
REMOTE
3.5(d) mm
33kW
S4
SP
+
GND
–
EXTERNAL SPEAKER
> ‗ 700 mW (8 W)
Rated input
D Battery protection
When the battery voltage decreases, the battery protection
function automatically turns the transceiver OFF. Select the
function according to your battery type.
(default: differs depending on the version)
• bAt.OF : Turns the function OFF. Select when you use the
BP-263 battery case.
• bAt.nm : Select when you use the BP-264 Ni-MH battery pack.
• bAt.LI : Select when you use the BP-265 Li-Ion battery pack.
NOTE: BE SURE to select an appropriate option accord-
ing to your battery type.
D Auto low power
Turns the auto low power function ON or OFF.
When the temperature goes below 0°C (+32°F), the function
automatically sets the output power to low.
In that case, the transmit power selections (Hi/Mid) are also
disabled.
(default: ALP.OF)
