Trouble Shooting Trouble Shooting - Icom IC-V80 Instruction Manual

If your transceiver seems to be malfunctioning, please check the following points before sending it to a service center.
PROBLEM
The transceiver does not turn
ON.
No sound comes from the
speaker.
Transmitting is impossible.
Transmitting using the VOX
function is impossible.
Contacting with another sta-
tion is impossible.
Frequency cannot be set.
A programmed scan does not
start.
A mem or y sc a n d o e s n o t
start.
The displayed frequency is er-
roneous.
POSSIBLE CAUSE
• The battery is exhausted.
• The battery polarity is reversed.
• Loose connection of a battery pack/case.
• Volume is too low.
• An external speaker or a cloning cable is
connected to the [SP] jack.
• The battery is exhausted.
• TX permission is inhibited.
• The VOX gain is set to OFF or too low.
• The microphone gain is too low.
• A different tone or code is used for the
tone/DTCS squelch.
• The key lock function is activated.
• The memory mode, Call channel mode, or
weather channel mode is selected.
• The memory mode, Call channel mode, or
weather channel mode is selected.
• The same frequency has been programmed
in the scan edge channels, "XA"–"Xb."
• The VFO mode or Call channel mode is
selected.
• Only one or no memory channel has been
programmed.
• The CPU has malfunctioned.
• External factors have caused a fault.
TROUBLE SHOOTING
SOLUTION
• Charge the battery pack, or replace the batteries.
• Check the battery polarity.
• Clean battery terminals.
• Rotate [VOL] to adjust to a desired level.
• Check the external speaker connection or remove
the cloning cable.
• Charge the battery pack, or replace the batteries.
• Set the TX permission setting to "ON" in the Set mode.
• Set the VOX gain to a suitable level.
• Set the microphone gain to a suitable level.
• Check the tone/DTCS by performing a tone scan.
• Push [FUNC](M), then push and hold [
(# ENT) for 1 sec. to cancel the key lock function.
• Push [VFO/MR/CALL] several times to select the
VFO mode.
• Push [VFO/MR/CALL] several times to select the
VFO mode.
• Program different frequencies in the scan edge
channels.
• Push [VFO/MR/CALL] several times to select the
memory mode.
• Program 2 or more memory channels.
• Reset the transceiver.
• Remove and re-attach the battery pack/case.
13
1
REF.
2
pp. 11–13
3
p. 13
4
p. 13
p. 14
5
–
6
pp. 11–13
7
p. 41
8
pp. 41, 53
p. 41
9
p. 34
10
11
]
p. 18
12
p. 15
13
p. 15
14
p. 25
15
16
p. 15
17
p. 25
18
p. 49
19
p. 2
50
