Icom IC-V80 Instruction Manual page 12

2
PANEL DESCRIPTION
[3] • [T.SCAN](3)
➥ Numeric input and DTMF code: '3'
➥ After pushing [FUNC](M), starts a tone scan.
(p. 34)
[4] • [DUP](4)
➥ Numeric input and DTMF code: '4'
➥ After pushing [FUNC](M), selects minus duplex,
plus duplex, or simplex operation. (p. 21)
[5] • [SCAN](5)
➥ Numeric input and DTMF code: '5'
➥ After pushing [FUNC](M), starts a scan. (pp. 29,
30)
[6] • [SKIP](6)
➥ Numeric input and DTMF code: '6'
➥ After pushing [FUNC](M), sets or cancels the
skip setting. (p. 30)
[7] • [PRIO](7)
➥ Numeric input and DTMF code: '7'
➥ After pushing [FUNC](M), starts a priority watch.
(p. 31)
[8] • [SET](8)
➥ Numeric input and DTMF code: '8'
➥ After pushing [FUNC](M), enters the Set mode.
(p. 38)
5
[9] • [H/M/L](9)
➥ Numeric input and DTMF code: '9'
➥ After pushing [FUNC](M), selects the output
power between high, middle and low. (p. 17)
[0] • [DTMF-M](0)
➥ Numeric input and DTMF code: '0'
➥ After pushing [FUNC](M), enters the DTMF
memory mode. (p. 35)
[M] • [FUNC](M)
➥ DTMF code: 'M (indication: E)'
➥ Push to access the second function of other keys.
[# ENT] • [ ](# ENT)
➥ DTMF code: '# (indication: F)'
➥ After entering a frequency, stores the frequency.
(p. 16)
➥ Push to exit the Set mode or Initial Set mode.
(pp. 38, 43)
➥ After pushing [FUNC](M), push and hold for 1 sec.
to turn the key lock function ON or OFF (p. 18)
