5
RECEIVE FUNCTIONS
D D Filter shape set mode (continued)
CW
(600Hz – )
Select the filter shape for CW mode in HF bands.
V/U SSB
(600Hz – )
Select the filter shape for SSB mode in VHF/UHF
bands.
CW
( – 500Hz)
Select the filter shape for CW mode in VHF/UHF
bands.
CW
(600Hz – )
Select the filter shape for CW mode in VHF/UHF
bands.
SHARP
The set filter shape is automatically used only
when the IF filter is set to 600 Hz or wider.
SOFT
The set filter shape is automatically used only
when the IF filter is set to 600 Hz or wider.
SHARP
The set filter shape is automatically used only
when the IF filter is set to 500 Hz or narrower.
SHARP
The set filter shape is automatically used only
when the IF filter is set to 600 Hz or wider.
5-14
