Icom IC-R9500 Instruction Manual page 165

D D Command table (continued)
Command Sub command
1A 050042
050043
050044
050045
050046
050047
050048
050049
050050
050051
050052
050053
050054
050055
050056
050057
050058
050059
050060
050061
050062
050063
050064
050065
050066
050067
050068
050069
050070
050071
Description
Send/read P25 received ID pop-
up indication setting
(0=OFF, 1=ON(Dec), 2=ON(Hex))
Send/read screen saver set
(0=OFF, 1=15 min., 2=30 min.,
3=60 min.)
Send/read output signal setting for
external display (0=OFF, 1=ON)
Send/read external display syn-
chronous pulse level setting
(0=L, 1=H)
Send/read opening message indi-
cation (0=OFF, 1=ON)
Send/read opening message con-
tents (see p. 13-10 for details)
Send/read date
(20000101=1st Jan. 2000 to
20991231=31st Dec. 2099)
Send/read time
(0000=00:00 to 2359=23:59)
Send/read clock 2 function
(0=OFF, 1=ON)
Send/read offset time for clock 2
(240001=–24:00 to 240000=+24:00)
Send/read clock 2 name
(Up to 3-character; see p. 13-10)
Send/read calibration marker
(0=OFF, 1=ON)
Send/read confirmation beep
(0=OFF, 1=ON)
Send/read beep audio frequency
(50=500 Hz to 200=2000 Hz)
Send/read panel lock function set
(0=ALL, 1=KEY)
Send/read speech language
(0=English, 1=Japanese)
Send/read speech speed
(0=Slow, 1=Fast)
Send/read S-level speech
(0=OFF, 1=ON)
Send/read speech with a mode
switch operation (0=OFF, 1=ON)
Send/read REC Speech set
(0=OFF, 1=ON)
Send/read Speech Mix function
set (0=OFF, 1=Operation, 2=All)
Send/read main dial auto TS
(0=OFF, 1=Low, 2=High)
Send/read main dial click function
mode set (0=Manual, 1=Auto)
Send/read main dial click function
set
(When above is Manual; 0=OFF,
1=ON or Auto; 0=OFF, 1=Auto)
Send/read main dial click (set
mode, etc) function
(0=OFF, 1=ON)
Send/read main dial operation
during scan (0=OFF, 1=Up/Down)
Send/read AFC limit set
(0=OFF, 1=ON)
Send/read SSB/CW synchronous
tuning function (0=OFF, 1=ON)
Send/read CW normal side set
(0=LSB, 1=USB)
Send/read APF type
(0=SHARP, 1=SOFT)
Command Sub command
1A 050072
050073
050074
050075
050076
050077
050078
050079
050080
050081
050082
050083
050084
050085
050086
050087
050088
050089
050090
050091
050092
050093
13-5
CONTROL COMMAND
Description
Send/read CI-V transceive set
(0=OFF, 1=ON)
Send/read RS-232C function
(0=CI-V, 1=Decode)
Send/read RS-232C decode
speed (0=300, 1=1200, 2=4800,
3=9600, 4=19200)
Send/read keyboard type
(00=English, 01=Japanese,
02=United Kingdom, 03=French,
04=French (Canadian),
05=German, 06=Portuguese,
07=Portuguese (Brazilian),
08=Spanish, 09=Spanish (Latin
American), 10=Italian)
Send/read keyboard repeat delay
(10=100 msec. to 100=1000 msec.)
Send/read keyboard repeat speed
(0=2.0 cps to 31=30.0 cps)
Send/read IP address set
(0000000000000001=0.0.0.1 to
0255025502550255=255.255.25
5.255)
Send/read subnet mask
(1=128.0.0.0 to
30=255.255.255.252)
Send/read TV type
(0=NTSC M, 1=PAL B/G, 2=PAL I,
3=PAL D, 4=SECAM K)
Send/read the LCD contrast of the
video signal from [VIDEO IN]
(0=0% to 255=100%)
Send/read the LCD brightness of
the video signal from [VIDEO IN]
(0=0% to 255=100%)
Send/read the saturation of the
video signal from [VIDEO IN]
(0=0% to 255=100%)
Send/read the hue of the video
signal from [VIDEO IN]
(0=0% to 255=100%)
Send/read the frame trimming of
the video signal from [VIDEO IN].
(0=OFF, 1=ON)
Send/read the wide screen set.
(0=OFF, 1=ON)
Send/read the output video signal
from [DATA IN]
(0=VIDEO IN, 1=LCD)
Send/read the width of the output
video signal from [DATA IN]
(0=1 (narrow) to 3=4 (wide))
Send/read setup of the output
video signal from [DATA IN]
(0=0IRE (JPN NTSC), 1=7.5IRE
(USA NTSC))
Send/read output saturation level
from [DATA IN]
(0=0% to 255=100%)
Send/read output hue level from
[DATA IN]. (0=0% to 255=100%)
Send/read the LCD contrast with
dimmer OFF condition
(0=0% to 255=100%)
Send/read the LCD brightness
with dimmer OFF condition
(0=0% to 255=100%)
13
