15
UPDATING THE FIRMWARE
■ Firmware update— PC
D D Connections
IC-R9500 (192.168.100.13)
Ethernet cable*
(Patch cable)
• IP address setting example
PC1
IP address 192.168.100.11
Subnet mask 255.255.255.0
Connect the IC-R9500 and the PC through a LAN
(Local Area Network) as follows.
PC1
(192.168.100.11)
Hub/Router*
=
to crossover port
PC2
192.168.100.12 192.168.100.13
255.255.255.0 255.255.255.0
15-6
PC2
(192.168.100.12)
to WAN
× × × ×
/Internet network
*Purchased separately
IC-R9500
