Icom IC-R9500 Instruction Manual page 166

13
CONTROL COMMAND
D D Command table (continued)
Command Sub command
1A 050094
050095
050096
050097
050098
050099
050100
050101
050102
050103
050104
050105
050106
050107
050108
050109
050110
050111
050112
050113
050114
050115
050116
050117
Description
Send/read the LCD unit brightness
with dimmer OFF condition
(0=0% to 255=100%)
Send/read the key backlight with
dimmer OFF condition
(0=0% to 255=100%)
Send/read the LCD contrast with
dimmer ON condition
(0=0% to 255=100%)
Send/read the LCD brightness
with dimmer ON condition
(0=0% to 255=100%)
Send/read the LCD unit brightness
with dimmer ON condition
(0=0% to 255=100%)
Send/read the key backlight with
dimmer ON condition
(0=0% to 255=100%)
Send/read scope max. hold
(0=OFF, 1=ON)
Send/read scope center frequen-
cy set (0=Filter center, 1=Carrier
point center, 2=Carrier point cen-
ter (Abs. Freq.))
Send/read waveform color for
receiving signal
(see p. 13-11 for details)
Send/read waveform color for
max. hold
(see p. 13-11 for details)
Send/read marker color for receiv-
ing signal
(see p. 13-11 for details)
Send/read marker color for max.
hold (see p. 13-11 for details)
Send/read scope peak excursion
(0=0 dB to 80=80 dB)
Send/read scope peak threshold
(0=–100 dB to 100=0 dB)
Send/read voice recorder's short
play time (3=3 sec. to 10=10 sec.)
Send/read voice recorder short
record time
(5=5 sec. to 30=30 sec.)
Send/read voice recorder's
recording quality
(0=SQ1 (8 kHz), 1=SQ2 (12 kHz),
2=HQ1 (16 kHz) 3=HQ2(24 kHz)
4=SHQ (48 kHz))
Send/read REC remote set
(0=OFF, 1=ON)
Send/read SPEECH Mix set
(0=OFF, 1=Operation, 2=All)
Send/read speech mix
(0=0% (Receive audio only) to
255=100% (Speech audio only))
Send/read memory bank limit set
for memory channel selection
(0=OFF, 1=ON)
Send/read memory bank limit set
for memory scan (0=OFF, 1=ON)
Send/read memory bank name
(Bank-0) (see p. 13-10 for details)
Send/read memory bank name
(Bank-1) (see p. 13-10 for details)
Command Sub command
1A
level
13-6
Description
050118 Send/read memory bank name
(Bank-2) (see p. 13-10 for details)
050119 Send/read memory bank name
(Bank-3) (see p. 13-10 for details)
050120 Send/read memory bank name
(Bank-4) (see p. 13-10 for details)
050121 Send/read memory bank name
(Bank-5) (see p. 13-10 for details)
050122 Send/read memory bank name
(Bank-6) (see p. 13-10 for details)
050123 Send/read memory bank name
(Bank-7) (see p. 13-10 for details)
050124 Send/read memory bank name
(Bank-8) (see p. 13-10 for details)
050125 Send/read memory bank name
(Bank-9) (see p. 13-10 for details)
050126 Send/read memory bank name
(Bank-A) (see p. 13-10 for details)
050127 Send/read memory bank name
(Bank-S) (see p. 13-10 for details)
050128 Set/read FFT scope averaging set
for FSK decoder
(0=OFF, 1=2, 2=3, 3=4)
050129 Set/read FFT scope waveform
color set for FSK decoder
(see p. 13-11 for details)
050130 Send/read FSK decode USOS
(0=OFF, 1=ON)
050131 Send/read FSK decode new line
code
(0=CR,LF,CR+LF, 1=CR+LF)
050132 Send/read clock selection for time
stamp (0=Local time, 1=Clock 2)
050133 Send/read frequency stamp
(0=OFF, 1=ON)
050134 Send/read FSK received text font
color (see p. 13-11 for details)
050135 Send/read time stamp text font
color (see p. 13-11 for details)
050136 Send/read skip scan set
(0=OFF, 1=ON)
050137 Send/read auto memory scan
memory clear
1=[AUTO] Long Push, 2=ON)
050138 Send/read auto scan screen set
when scan start (0=OFF, 1=ON)
050139 Send/read NB1 depth
(0=1 to 9=10)
050140 Send/read NB1 width
(0=0 to 255=100)
050141 Send/read NB2 depth
(0=1 to 9=10)
050142 Send/read NB2 width
(0=0 to 255=100)
050143 Send/read TS (1 Hz) as selectable
tuning step for FM
(0=OFF, 1=ON)
050144 Send/read TS (10 Hz) as selec-
table tuning step for FM
(0=OFF, 1=ON)
050145 Send/read TS (100 Hz) as selec-
table tuning step for FM
(0=OFF, 1=ON)
050146 Send/read TS (1 kHz) as selec-
table tuning step for FM
(0=OFF, 1=ON)
set (0=OFF,
