D D Separately recording audio and frequency
When using a stereo tape recorder for recording,
received audio and a frequency with a synthesized
voice can be separately recorded.
When recording this way, you can search ahead of
the audio signal recorded in the tape recorder using
the frequency recording channel search.
• Be sure the "REC SPEECH" item is turned ON, and "SPEECH Mix" item is select OFF in the others set
mode (p. 11-11).
[SPEECH OUT]
350 mVrms
4.7 kΩ
[REMOTE] jack
[AUX IN] jacks L and R
INSTALLATION AND CONNECTIONS
[REC REMOTE]
[LINE OUT]
350 mVrms
4.7 kΩ
2-9
When you wish to control a tape
recorder via the REMOTE jack.
REAR
2
