SCANS

■ Scan types

PROGRAMMED SCAN
Repeatedly scans between two scan edge frequencies
(scan edge memory channels PxA and PxB).
Scan edge
PxA or PxB
This scan operates in both VFO and memory modes.
MEMORY SCAN
Repeatedly scans all programmed memory channels.
Mch 2
★2
*"★1," "★2" and "★3" show that the channel
Mch 1
★1
is specified as the select memory.
Mch 99
★1
This scan operates in memory mode.
PRIORITY SCAN
Continuously switches between monitoring displayed
frequency and specified memory channel (priority
channel).
VFO
Frequecy
Memory
Channel
This scan operates in both VFO and memory modes.
FINE SCAN
Scans in 10 Hz steps when squelch is open (around the
signal) while program scan or ∂F scan.
Squelch open
Scan edge
PxA or PxB
This scan operates in both VFO and memory modes.
Scan edge
PxB or PxA
Scan
Jump
Blank channel
Mch 3
Mch 4
★1
Mch 5
Mch 6
Mch 7
★3
Memory
Channel
Priority Channel
or
Memory
Channel
Priority Channel
Scan edge
(10 Hz steps)
PxB or PxA
Scan
Jump
∂F SCAN
Repeatedly scans within ∂F span.
∂F frequency
–
This scan operates in both VFO and memory modes.
SELECT MEMORY SCAN
Repeatedly scans all or one of 9 select memory channels.
Mch 1
★1 ★1
This scan operates in memory mode.
MODE SELECT MEMORY SCAN
Repeatedly scans a selected mode (ignoring other
modes) while memory scanning.
FM
Mch 1
This scan operates in memory mode.
AUTO MEMORY WRITE SCAN
Auto memory write scan operates in the same way as
programmed scan. However, when a signal is received,
the received frequency is automatically written into a
memory channel in the auto write bank.
Scan edge
PxA or PxB
This scan operates in both VFO and memory modes.
8-2
Start frequency
Scan Scan
Jump
Blank channel
Mch 2 Mch 3
★2 ★1
*"★1," "★2" and "★3" show that the channel
is specified as the select memory.
Mch 99 Mch 7
★1 ★1
USB
FM
Mch 2 Mch 3
FM FM
Mch 99 Mch 7
Mch A0 Mch A99
Program Program
Pause Pause
Scan
Jump
+∂F frequency
Mch 4
Mch 5
★1
Mch 6
★3
CW
Mch 4
FM
Mch 5
FSK
Mch 6
Scan edge
PxB or PxA
