■ Level set mode

FSK Tone (Bass)
Sets the bass level of the receive audio in FSK mode
from –5 to +5. (default: 0)
FSK Tone (Treble)
Sets the treble level of the receive audio in FSK mode
from –5 to +5. (default: 0)
De-Emphasis (FM 50k)
De-emphasis is the use of an amplitude-frequency
characteristic complimentary to the one used for pre-
emphasis prior to transmission.
Sets the de-emphasis circuit ON and OFF when the
50 kHz width filter is used in FM mode. (default: OFF)
(FM 15k)
Sets the de-emphasis circuit ON and OFF when the
15 kHz width filter is used in FM mode. (default: ON)
(FM 7k)
Sets the de-emphasis circuit ON and OFF when the
7 kHz width filter is used in FM mode. (default: ON)
AF High Cut (FM 50k)
Sets the AF high cut filter circuit ON and OFF when
the 50 kHz width filter is used in FM mode. (default:
OFF)
(FM 15k)
Sets the AF high cut filter circuit ON and OFF when
the 15 kHz width filter is used in FM mode. (default:
ON)
(FM 7k)
Sets the AF high cut filter circuit ON and OFF when
the 7 kHz width filter is used in FM mode. (default:
ON)
(WFM)
Sets the AF high cut filter circuit ON and OFF in WFM
mode. (default: OFF)
(continued)
OFF
ON
ON
OFF
ON
ON
OFF
11-5
