11
SET MODE

■ Others set mode

MAIN DIAL Auto TS
Sets the auto tuning step function for the main dial.
When rotating the main dial rapidly, the tuning step
automatically changes several times as selected.
There are 2 type of auto tuning steps: HIGH (Fastest)
and LOW (Faster). (default: HIGH)
MAIN DIAL Click Mode
Sets the dial click function for the main dial from Auto
or Manual.
MAIN DIAL Click
Sets the dial click function ON or OFF. This item can
be set when the previous item "MAIN DIAL Click
Mode" is set to "Manual."
NOTE: When the previous item is set to "Auto," this
item is fixed "Auto."
MAIN DIAL Click (Set mode, etc)
Selects the dial click function while setting the set
mode items, etc. from ON and OFF. (default: ON)
MAIN DIAL Operation (SCAN)
Selects the main dial function while scanning from
OFF and Up/Down. (default: Up/Down)
AFC Limit
The AFC function automatically compensates the tun-
ing when a received frequency drifts or goes off fre-
quency.
This item sets the AFC limit function ON and OFF.
(continued)
11-12
High
• HIGH : Auto tuning step is turned ON. Fastest tun-
ing step during rapid rotation. (default)
• LOW : Auto tuning step is turned ON. Faster tun-
ing step during rapid rotation.
• OFF : Auto tuning step is turned OFF.
Auto
• Auto : Sets the dial click function automatically
when a tuning step is set higher than 5
kHz or changing the set mode contents,
etc. (default)
• Manual : Sets the dial click function manually.
NOTE: When "Manual" is selected, set the next
item "MAIN DIAL CLICK" ON or OFF.
Auto
• Auto : Selection can not be changed, set the previ-
ous item to "Manual" in advance. (default)
• ON : The dial click function is ON, "CLICK" indica-
tor appears on the display.
• OFF : The dial click function is OFF.
ON
• ON : The main dial click function is ON.
• OFF : The main dial click function is OFF.
Up/Down
• OFF : The main dial stops scan.
• Up/Down : The main dial changes scanning direc-
tion Up or Down.
ON
• ON : AFC function stops to tune when frequency
goes off the limited frequency range even if
received frequency is off frequency. (default)
• OFF : AFC function continues to tune until displayed
frequency changes to reflect the center of the
signal.
