Data Link Configuration
Section Format
© National Instruments Corporation
This appendix explains how to structure the Data Link Configuration
section of your Device Configuration
The Data Link Configuration section of your Windows
Configuration file must be converted to C code and linked with your
application before the Round Card can communicate on the Fieldbus
network. The code generated by running this file through the
Configuration Generator automatically configures your board. When a
parameter is changed over the Fieldbus, the parameter is updated in
nonvolatile memory.
Following is a description of the format of the Data Link Configuration
section.
The first line of the Data Link Configuration section is as follows:
[Data Link]
The general line format for all other lines is as follows:
variable=value
where the valid variable names and values are defined in Table A-1
Table A-1. Valid Variable Names and Values for the Data Link Configuration
Variable Name
devClass
nodeAddress
indicates whether the device functions as a basic device or a
devClass
link master device.
.ini
Valid Values
BASIC
LINKMASTER
0x10–0xfb
A-1
80188EB-Based Fieldbus Round Card User Manual
Appendix
A
file.
Device
.ini
Default
none
none
