Dc4 Dc4 Esc Vt Search For A Blank Line (Without Any Marker). (Compuprint); Dc4 Dc4 Esc X Reads The Id Of The Cut Sheets. (Compuprint) - Compuprint MDP 30FB Programmer's Manual

DC4 DC4 ESC X
Reads the id of the cut sheets. (Compuprint)
ASCII Code
Hexadecimal Value
Decimal Value
This command reads the markers of the cut sheets.
n
Number of markers. (1 < n < 32)
x Horizontal position from the center of the first marker in mm from the first prints
position.
y Vertical position from the center of the markers in mm from the upper page margin.
l
Distance between the markers in mm.
DC4 DC4 ESC VT
Search for a blank line (without any marker). (Compuprint)
DC4 DC4 ESC VT o w
ASCII Code
Hexadecimal 14 14 1B 0B o w
Value
20 20 27 11 o w
Decimal Value
This command searches for a blank line.
o Send a reply on the serial interface
o = 1, send a reply
o = 0, do not send a reply
w Marker width in 1/120"
DC4 DC4 ESC X n x y l
14 14 1B 58 n x y l
20 20 27 88 n x y l
118
