Sets Amplification Factor. (Compuprint) - Compuprint MDP 30FB Programmer's Manual

DC4 DC4 ESC J

Sets amplification factor. (Compuprint)

DC4 DC4 ESC J h v
ASCII Code
Hexadecimal Value 14 14 1B 4A h v
Decimal Value 20 20 27 74 h v
This command sets the required amplification factor to be applied to the current font.
h It is the horizontal amplification factor, the value range is 1 to 4. It is applied
to the basic symbols.
v It is the vertical amplification factor, the value range is 1 to 255.
0 values for either h and v parameters keep the related current amplification factor
unchanged.
The internally available symbol's amplification algorithms support the following
character attributes, that may be selected by means of the available control sequences
within the currently active emulation: double width, double-height, emphasized,
double strike, subscript, superscript, italics, proportional, compressed.
Doublewide and double-high attributes must be lower than 2.
114
