Compuprint MDP 30FB Programmer's Manual page 109

2 Print the bar code symbol with both
check digits generated by the printer
and put at the end of the data. The
nd
2 check digit is IBM Modulus-10;
st
the 1 check digit is IBM Modulus-
10 also.
3 Print the bar code symbol with both
check digits generated by the printer
and put at the end of the data. The
nd
2 check digit is IBM Modulus-10,
st
the 1 check digit is NCR Modulus-
11: if modulus is 10, it is an error
and question marks will be printed
in place of HRC string, if possible.
4 Print the bar code symbol with both
check digits generated by the printer
and put at the end of the data. The
nd
2 check digit is IBM Modulus-10,
st
the 1 check digit is IBM Modulus-
11: if modulus is 10, it is an error
and question marks will be printed
in place of HRC string, if possible.
The printer-generated second check digit does not show on required HRC string.
6 Print the bar code symbol with both
check digits generated by the printer
and put at the end of the data. The
nd
2 check digit is IBM Modulus-10,
st
the 1 check digit is the complement
to 11 of IBM Modulus-11 algorithm
applied to the received string: if the
modulus is 0 or 1 check digit is 0.
7 Print the bar code symbol with both
check digits generated by the printer
and put at the end of the data. The
nd
2 check digit is IBM Modulus-10,
st
the 1 check digit is the complement
to 11 of NCR Modulus-11 algorithm
applied to the received string: if the
modulus is 0 or 1. It is an error and
question marks will be printed in
place of HRC string, if possible.
8 Print the bar code symbol with both
check digits generated by the printer
and put at the end of the data. The
nd
2 check digit is IBM Modulus-10,
st
the 1 check digit is the complement
to 11 of IBM Modulus-11 algorithm
applied to the received string: if the
modulus is 0 or 1. it is an error and
question marks will be printed in
place of HRC string, if possible.
107
