Quick Opening Valve Characteristic

Table 12 contains values that approximate the characteristic of a quick opening control valve. When the
QUIK custom characterization type is selected, the values in Table 12 are automatically loaded into the
actuator configuration to produce the characteristic as presented in the graph. The Xn VAL is the input
value as a percentage of range and Yn VAL is the characterized output (actuator shaft position) as a
percentage of range.
Xn VAL
Order
% of
Range
0 0
1 5
2 10
3 15
4 20
5 25
6 30
7 35
8 40
9 45
10 50
11 55
12 60
13 65
14 70
15 75
16 80
17 85
18 90
19 95
20 100
Revision 6 HercuLine™ 2000 Series Actuator - Installation, Operation and Maintenance Manual
7/07

Table 12 Quick Opening Valve Characteristic

Yn Val
% of
Range
0
10
20
100
30
95
90
40
85
50
80
75
60
70
70
65
60
77
55
82
50
86 45
40
88
35
90
30
25
92
20
94
15
10
95
5
96
0
97.5
98.5
99.5
100
