Lock Set Up Group

Table 19 lists the parameters and selections available for the SET LOCK group.
Actuator Lower
Display
Prompt
LOCKID
LOCK
MAENAB
Revision 6 HercuLine™ 2000 Series Actuator - Installation, Operation and Maintenance Manual
7/07

Table 19 Lock Set Up Group Parameters

Selections or
Range of Setting
0 to 4095 PASSWORD LOCK — 4-digit password can be selected to
provide security access to calibration information, set up
parameters and supervisory functions. Password can be a
number from 0 to 4095.
default = 0
LOCK OUT FEATURE — Selects lockout security for
calibration and supervisory functions, and set up groups.
None — No lockout of any calibration or set up groups. You
NONE
select and change set up group values, and perform field
calibration.
Calibration — Lockout for calibration groups SET CALINP,
CAL
SET CALMTR, SET CALOUT and CAL POSOUT only. You
can select and change set up group values.
Configuration — Lockout for calibration groups and set up
CONF
group configuration. You can only scroll through and view
set up group values.
Full — Lockout for calibration and all set up group values.
FULL
Only SET LOCK and READ STATUS groups are accessible.
default = NONE
Manual / Auto — Allows the ability to lockout mode changes
from the front panel.
Disabled — Disables the front panel auto / manual switch
DIS
functionality.
ENAB
Enabled — Enables the front panel auto / manual switch
default = ENAB
functionality.
Set Up and Calibration Procedures
Parameter Definition/PDA HercuLink
Lock Set Up Group
®
Prompt
