Downloadable Fonts
<Memory Slot Number> is the memory slot location (1-255) where the graphic will be saved
in the printer's memory. The printer uses the same TCI of "8" to select downloadable fonts
or graphics. Therefore a font and a graphic cannot have the same Slot Number or CGN
number.
<Rotation> is an 8-bit integer, 0 for an upright font and 1 for a 90-degree rotated image.
<Count> is a 32-bit integer, least significant byte first. This is the number of bytes that the
image uses.
<Image Data> is the graphic image data that has been converted to ASCII-HEX.
ASCII-HEX Conversion
The ASCII-HEX conversion is performed by OR'ing the most significant and least significant
nibbles of every byte with "30" HEX.
For Example: To convert the byte "6C" to ASCII-HEX, simply OR the first and second
nibbles with "30" HEX. This results in the two bytes "36" HEX and "3C" HEX. This
conversion results in a file size that is twice as big as the source but the data can now be
transmitted over a 7-bit data connection. Refer to Figure 13.
8.3

Font Structure

The following font structure is offered to programmer's who wish to use their own programs
to convert fonts. The font structure consists of a set of data structures and location offsets
to those structures. All data is stored in binary form. Multi-byte values are stored "least
significant byte" first. The printer can store a font of approximately 64KB or less in any one
memory slot location.
(Word is a 16-bit value, Byte is an 8-bit value, and Label is a location within the file)
Label start:
Word, Word, lookup_table_offset
Word tallest_char
Word widest_char
Byte default_spacing
Byte byte_width
Byte first_char
Byte last_char
Byte default_char
Label lookup_table
68
the beginning of the file
distance in bytes from start to beginning of
lookup_table (4 bytes)
height of graphic image in dots
Width of graphic image in dots
Default spacing, usually 0
Width of graphic image in bytes
20 HEX
20 HEX
20 HEX
beginning of lookup table
