Chapter 5
5.6.5 TCI (Text Conversion Identifier)
The TCI parameter determines how the text string will be generated. The TCI is used to
select text, bar codes, lines, downloadable font and graphics. The TCI values can be
determined using Table 9 below. For example, a TCI of "1" for the text string data "012345"
would print the text "012345" while a TCI of "15" would produce an I 2 of 5 symbology.
TCI VALUE
1
2
3*
6
8
12
13
14
15
16
17*
20
21
22*
23*
24
25
26
28*
29*
32*
33*
36
37
38
40
42
43
44
50
51
* Refer to Section 9.3
322M Operator's Manual
TCI DESCRIPTION
Regular Text (standard embedded fonts)
Text Surrounded by Asterisks
Text with UPC-A / UPC-E Checksum Digit Added
Line Draw
Downloadable Fonts and Graphics
UPC-A Symbol
UPC-E Symbol (Send 11 Digits)
UPC-E Symbol (Send 7 Digits)
Interleaved 2 of 5 Symbol
Code 39 Symbol
Text with UPC-E Checksum and Extended Bars Added
EAN-13 Symbol
EAN-8 Symbol
Text with EAN-13 Checksum and Extended Bars Added
Text with EAN-8 Checksum and Extended Bars Added
MSI 1 Symbol (Modified Plessey)
MSI 2 Symbol (Modified Plessey)
MSI 3 Symbol (Modified Plessey)
Text with MSI Checksum Added – Type 1
Text with MSI Checksum Added – Type 2
Text with UPC-A Checksum and Extended Bars Added
Text with UPC-A with Extended Bars Added
Postnet Symbol (Zip+4)
Postnet Symbol (Zip+6)
MaxiCode Symbol
Code 128 Symbol (Automatic Compression)
Codabar Symbol
Code 93 Symbol
AS-10 Symbol
UCC/EAN 128 Symbol
Text with EAN 128 Information
Table 9
Designing Labels Using LDS
TCI Values
33
