Table 11 Cgn - Bar Code Symbologies - Microcom 322M Operator's Manual

Chapter 5
SYMBOL
Code 39
I 2 of 5
UPC / EAN *
UPC Readable *
Code 128 & UCC / EAN 128 *
Codabar
Code 93
AS-10
Maxicode (CGN = Mode)
MSI (Modified Plessey)
* These Symbologies must use the CMX or CMY multipliers by 2 to produce a 80% ratio.
** The "FO" field represents the available Field Orientation or print rotation. See section
5.6.7.
322M Operator's Manual
Bar Code Symbologies
CGN
VALUE
2
3
5
8
2
3
5
-
-
-
2
3
5
-
-
2
3
4
5
6
-
CGN – Bar Code Symbologies
Table 11
Designing Labels Using LDS
RATIO HEIGHT
2:1 1
3:1 1
5:2 1
8:3 1
2:1 1
3:1 1
5:2 1
40 % 1
40 % 1
40 % 1
2:1 1
3:1 1
5:2 1
2:1 1
2:1 1
- -
- -
- -
- -
- -
1:1 1
SPACING FO **
2 0123
2 0123
2 0123
3 0123
- 0123
- 0123
- 0123
- 0123
- 0123
- 0123
- 0123
- 0123
- 0123
- 0123
- 0123
- 0123
- 0123
- 0123
- 0123
- 0123
- 0123
35
