Chapter 1:
1.1 General Specifications
Width
Height
Depth
Weight
Electrical
Current
Temperature
Humidity
SRAM Memory
Flash Memory
Agency Approvals
RS-232D Serial
Flow Control:
Baud Rates:
Parity:
Data Bits:
1.2 Printing Specifications
Print Type
Print Resolution
Maximum Print Speed
Maximum Print Width
Print Length
1.3 Media Specifications
Media Types
Maximum Media Thickness
Maximum Media Width
322M Operator's Manual
Printer Specifications
7.63" (194mm)
4.0" (102mm)
3.63" (92mm)
3.5 lbs. (1.6 kg)
Universal +24 VDC
3 Amps maximum
40° F – 104° F (5° C – 40° C) Operating
10% – 85%, non-condensing
512K bytes
512K bytes
CUL, CE, and complies with FCC Class A.
RS-232D, 9 pin D-Sub connector (DCE)
XON, XOFF, and CTS
110 to 115200
Odd, Even, and None
7 or 8
Table 1 General Specifications
Direct Thermal
203 DPI (8 dots/mm or 0.0049" per dot)
6"/sec. (152mm/sec.)
2.83 inches or 575 dots (72mm)
3.15" or 640 dots (80mm) – When used
with the Heavy Media Printing Option
50" (1270mm) using standard memory
Table 2 Printing Specifications
Continuous, die-cut, preprinted and tag
stock either rolled or fanfold.
.006" (.15mm)
3.5" (89mm)
Table 3 Media Specifications
