Chapter 1: Printer Specifications - Microcom 438TC Operator's Manual

Chapter 1:
1.1 General Specifications
Width*
Height*
Depth*
Weight*
Electrical
Current
Temperature**
Humidity
SRAM Memory
Code Flash Memory
User Flash Memory
Agency Approvals
Interface Communications
Flow Control
Baud Rate
Parity
Data Bits
* NOTE: Listed specifications are based on a standard print mechanism and may vary
** NOTE: Higher temperature applications are possible; please contact your Microcom
Corporation Sales representative for more information.
1.2 Printing Specifications
Print Type
Print Resolution
Maximum Print Speed
Maximum Print Width
Maximum Print Length
Minimum Print Length
438TC Operator's Manual - 880050-0100
Printer Specifications
7.3" (185 mm)
7.4" (188 mm)
5.8" (148 mm)
10.2 lbs. (4.6 kg)
+24 VDC
3 Amps maximum
40° F – 122° F (5° C – 50° C), operating
10% – 85%, non-condensing
512 K
512 K
8 MB
Designed to meet CUL, CE, and complies with FCC
Class A
RS232, USB, Version 1.1 supported, Optional
Centronics Parallel, and Ethernet Ports
XON/XOFF and CTS/RTS Hardware
115200
Odd, Even, and None
7 or 8
Table 1-1 General Specifications
based on final configuration.
Direct Thermal
203 DPI (8 dots/mm = 0.0049" per dot)
300 DPI (12 dots/mm = 0.0032" per dot)
8"/sec. (203 mm/sec.)
203 DPI = 4.098" (104.10mm); 832 dots
300 DPI = 4.252" (108 mm); 1,280 dots
50" (1,270 mm)
0.25" (6 mm)
Table 1-2 Printing Specifications
1-1
