Multi-VLAN example
Table 90: Command set and explanations for multi-VLAN example (continued)
Command
encapsulation dot1q 1
ip address 192.168.1.254
255.255.255.0
!
interface FastEthernet0/1.10
encapsulation dot1q 10
ip address 192.168.10.254
255.255.255.0
ip helper-address 192.168.1.100
P330 configuration (bind-to-static option)
set port vlan-binding-mode 1/1 static
set port static-vlan 1/1 10
set trunk 1/1 dot1q
set port spantree disable 1/1
set port vlan 10 1/2
set port spantree disable 1/2
set port vlan 10 1/3
set port spantree disable 1/3
set port vlan-binding-mode 1/5 static
set port static-vlan 1/5 10
set port spantree disable 1/5
396 Avaya Application Solutions IP Telephony Deployment Guide
Notes
Forwards DHCP requests to the DHCP
server.
1
Port in static binding mode by default,
but command shown.
In addition to v1, v10 statically bound to
port.
Port connected to Cisco router is an
802.1Q trunk port.
Port/native VLAN changed to 10 on this
port.
Port in static binding mode by default,
but command shown.
In addition to v1, v10 statically bound to
port, but not a trunk port.
Port 1/12 for the DHCP/TFTP server
already has port/native VLAN 1.
2 of 5
