G350 Specifications
The G350 chassis features six media module slots (V1 to V6) and various fixed ports and
buttons. V1 to V5 are G700 form factor media module slots capable of housing existing G700
media modules. V6 is a high-density media module (HDMM) slot for housing new high capacity
media modules (see below).
Figure 8: G350 chassis
The following tables describe the functions of the fixed ports and buttons on the G350 front
panel.
Table 4: Fixed ports on the G350 front panel
Port
TRK
LINE 1, LINE2
CC
WAN 1
LAN 1
CON
USB
Description
An analog trunk port. Part of an integrated analog media
module.
Analog telephone ports of the integrated analog media module.
An analog relay between TRK and LINE 1 provides Emergency
Transfer Relay (ETR) feature. {ETR could be confusing term}
RJ-45 port for ACS (308) contact closure adjunct box.
RJ-45 10/100 Base TX Ethernet port.
RJ-45 Ethernet LAN switch port.
Console port for direct connection of CLI console.
USB port, not supported in this release.
Small to mid-size enterprise
Issue 3.4.1 June 2005
43
