Such continuous monitoring and the alarming capability existing as part of the Media Server
helps to reduce the failure diagnostic period and as a result much shorter recovery time from
outages.
Table 49: S8500 hardware availability in Multi-Connect and IP-Connect
Configurations
Sub-system
S8500 Simplex Server
S8500 Server Complex
MCC1/SCC1 Media Gateways
(Multi-Connect)
G650 Media Gateway
(IP-Connect)
1. Server Complex includes S8500 server, Ethernet Switch (hardware MTBO = 16 years)
and UPS.

S8500/G650

S8500
The Avaya S8500 Media Server Platform is a simplex Linux-based server running Avaya
Communication Manager (CM) software that will replace the DEFINITY SI and S8100
processing platforms for smaller sites and for customers who do not require a duplicated server
complex.
The S8500 system supports the Avaya MCC1, SCC1, CMC1, and G650 Media Gateways. The
Avaya G700 and G350 Media Gateways are also supported, provided that there is a TCP/IP
connection between the media gateway and a C-LAN circuit pack located in a MCC1, SCC1,
CMC1, or G650 Media Gateway. The S8500 has the capacity to support up to 64 port networks.
Up to 3 MCC1 port networks can be directly connected. Even though the server capacity
supports up to 64 port networks, the first release supports up to 400 stations (80% IP).
The S8500 Media Server allows for a seamless migration from DEFINITY SI, CSI, R, and
S8100 platforms. However, the S8500 will not support traditional circuit-switched Center Stage
Switch or ATM Port Network Connectivity.
Standard (duplex) reliability
Failures/
year
0.12
1
0.43
0.15
0.05
MTBO Availability
8.1 99.994
2.3 99.98
6.5 99.993/
99.997
20 99.998
