Cable Routing and Pinouts
MESAN52 RAID Disk Drive Section Cable Routing
From MESAN52
J2, LED Board
J3, LED Board
J14, J16, Backplane
J18, J19, Backplane
CH0, Backplane
CH1, Backplane
J2: MCBL229A, RAID LCD Cable Pinout
Pin
Signal
1
Ground
2
No Connect
3
Ground
4
DISPRS
5
DISPRW
6
DISPENB
7
Data 0
J3: MCBL230A, RAID LED Cable Pinout
Pin
Signal
1
Ground
2
RAID present
3
Channel bad
4
Channel good
5
RPS bad
Cable
To
MCBL229A
LCD Board, J5
MCBL230A
LCD Board, J6
MCBL145A (or)
MPWS175 P4 and P5 (Non-RAID only)
MCBL050A
Power Distribution Board, J26 and J27
(RAID only)
MCBL145A (or)
MPWS175 P2 and P3 (Non-RAID only)
MCBL050A
Power Distribution Board, J23 and J24
(RAID only)
MCBL361A
RAID Controller, CH 0
MCBL361A
RAID Controller, CH 1
Pin
Signal
8
Data 1
9
Data 2
10
Data 3
11
Data 4
12
Data 5
13
Data 6
14
Data 7
Pin
Signal
6
RPS green (good)
7
RFAN green (good)
8
RFAN green (good)
9
Ground
10
RAID bell (alarm)
Pin
Signal
15
No Connect
16
Menu
17
Escape
18
Down
19
Enter
20
Up
59
