52
Cable Routing and Pinouts
From
J2
J5
J6
J100
J2: MCBL203A, System Status Cable Pinout
Refer to "Power Distribution Board (MSMT498 or MSMT499)" for the pinout of the system
status cable. See table "J1: MCBL203A, LCD Board System Status Pinout."
J5: MCBL229A, Disk Drive LCD Cable Pinout
Refer to "Disk Drive Section (MESAN52)" for the pinout of the RAID LCD cable. See table
"J2: MCBL229A, RAID LCD Cable Pinout."
J6: MCBL230A, Disk Drive LED Cable Pinout
Refer to "RAID Disk Drive Section (MESAN52)" for the pinout of the RAID LED cable.
See table "J3: MCBL230A, RAID LED Cable Pinout."
J100: MCBL208A, Power On/Off Pinout
Pin
Signal
1
Off
2
On
Cable
MCBL203A, System Status
MCBL229A, LCD
MCBL230A, LED
MCBL208A, Power On/Off
Wire Color
Black
Red
To
Power Distribution Board (MSMT498 or
MSMT499), J1
Disk Drive Section, J2 (RAID only)
Disk Drive Section, J3 (RAID only)
Keyswitch
Pin
Signal
Wire Color
3
Reset
Brown
4
Ground
Orange
