MIDI/Game
The MIDI/Game port connects a game joystick or a MIDI device, such as a musical
keyboard or synthesizer, to the system.
15
9
Parallel
The Parallel port is used almost exclusively for printers, but is compatible with any
peripheral device designed to interface with a standard Centronics-type parallel port. Use
only shielded cables with the parallel port (DB-25).
14
25
Pin
Signal
1
1
+5V
2
Fire button 0
3
X-axis,
joystick 1
4
Ground
5
Ground
6
Y-axis,
8
joystick 1
7
Fire button 1
8
+5V
1
Pin
Signal
1
-Strobe
2
Data 0
3
Data 1
4
Data 2
5
Data 3
6
Data 4
7
Data 5
8
Data 6
13
9
Data 7
Pin
Signal
9
+5V
10
Fire button 2
11
X-axis, joystick 2
12
MIDI out
13
Y-axis, joystick 2
14
Fire button 3
15
MIDI in
Pin
Signal
10
-ACK -
Acknowledge
11
Busy
12
PE - Paper Empty
13
+Select
14
-Auto FDXT -
Auto Feed
15
-Error
16
-Init - Start
17
-SLCTIN - Select
18-25
Ground
73
