Intergraph InterServe 800 SL System Reference Manual page 66

54
From
J7/J8/J9/10
J11
J12
J15
J16, J17
(MSMT498)
J18/J19
J20
J21, 22, J24, J25
J21, 22 (MSMT499)
J23
J24
J25
J1: MCBL203A, LCD Board System Status Pinout
Pin Signal
1 Ground
2 +5V Fuse
3 Ground
4 DISPRS
5 DISPRW
6 DISPENB
7 Data 0
8 Data 1
9 Data 2
10 Data 3
11 Data 4
12 Data 5
J3: MCBL388A, Reset Cable Pinout
Pin Signal
1 Ground
PS Conf. Side Cable
* 1 MCBL202A
* 1 MCBL319A
* 1 MCBL210A
* 1 MCBL385A
- 1 n/a
+ 1 P1/P2
* 2 MCBL206A
* RAID 2 MCBL050A
+ JBOD 1 MCBL049A
* 2 MCBL085A
+ 2 P7
+ 2 P3
Pin Signal
13 Data 6
14 Data 7
15 VCC Fuse
16 Menu
17 Escape
18 Down
19 Enter
20 Up
21 System/RAID
22 No Connect
23 Ground
Pin Signal
2 Reset
To
Main Chassis Fans
J27, System Board
Intruder Switch
Pins 22, 23 on System Board
550 Watt Power Supplies
300 Watt Power Supply
CD-ROM and Floppy Disk Drive
RAID Section J14, J16, J18, J19
300 Watt Power Supply
Auxiliary Drives
300 Watt Power Supply
300 Watt Power Supply
Pin Signal
24 VCC Fuse
25 CHBAD
26 CHGOOD
27 PSBAD
28 PSGREEN
29 FANBAD
30 FANGREEN
31 Ground
32 Bell
33 No Connect
34 No Connect
