Intergraph InterServe 800 SL System Reference Manual page 68

56
J15: MCBL385A, Power Cable Pinout
Pin Signal
1 No connect
J16, J17: 550 Watt Power Supplies Cable Pinout
Refer to "550 Watt Power Supplies (MPWS139)" for the pinout of these connectors. See the
table on page 63.
J18, J19: 300 Watt Power Supplies Cable Pinout
Refer to "300 Watt Power Supply (MPWS175)" for the pinout of these connectors. See the
table on page 61.
J20: MCBL206A,
Floppy Disk Drive Cable Pinout
Pin Signal
1 +5V
2 Ground
CD-ROM Drive Cable Pinout
Pin Signal
1 +12V
2 Ground
J21/22/24/25: MCBL050A, RAID Power and MCBL085A, Auxiliary Drive Pinout
Pin Signal
1 +12V
2 Ground
Pin Signal
2 PBE
Wire Color Pin
Red 3
Black 4
Wire Color Pin
Yellow 3
Black 4
Wire Color Pin
Yellow 3
Black 4
Signal Wire Color
Ground Black
+12V Yellow
Signal Wire Color
Ground Black
+5v Red
Signal Wire Color
Ground Black
VCC, +5v Red
