Follow these population rules to correctly install the DIMMs:
u
Remember that you must install DIMMs one at a time.
u
Install DIMMs one bank at a time; begin with bank 0 (nearest to the processors) or the
first open bank; end with bank 3.
u
Press the DIMM into the socket at a 90 degree angle. Do not rock the DIMM; apply
even pressure along the top edge of the DIMM.
The following tables show possible memory configurations. Each bank contains one socket.
Memory size
64 MB
128 MB
256 MB
NOTE The 32 MB x 72 registered DIMM cannot be mixed with any other type of DIMM.
Memory
64 MB
128 MB
256 MB
384 MB
512 MB
512 MB
1 GB
The system board features four DIMM sockets, which combined can hold up to 1 GB of
Synchronous Dynamic Random-Access Memory (SDRAM). See the system board diagram
in Chapter 5, "System Board," for socket locations.
See Chapter 2, "Servicing the System," to install a memory upgrade. Restart the system
after adding or replacing DIMMs. The computer detects the new memory automatically.

Adding a Processor

You can upgrade a single processor system to a dual processor system. Processors are
mounted in a processor retention module which surrounds the processor slots. See the
system board figures in Chapter 5, "System Board," for the location of processor slots and
related connectors.
Configuration (ECC)
8 MB x 72
16 MB x 72
32 MB x 72 registered
Bank 0 Bank 1
DIMMs DIMMs
64 MB
128 MB
128 MB 128 MB
128 MB 128 MB
128 MB 128 MB
256 MB 256 MB
256 MB 256 MB
Bank 2 Bank 3
DIMMs DIMMs
128 MB
128 MB 128 MB
256 MB 256 MB
31
