Disk Drives (FDSK xxx )
You can use any of the following SCSI disk drives in the system:
RPM
10,000
10,000
7,200
7,200
7,200
7,200
The following figure shows the jumper connectors J2 and J6 on the 7,200 RPM 4.3 GB disk
drive. Remove the drive from its bracket to access J2. The RAID disk drives use one
connector that carries power, data, and SCSI ID signals. This connector plugs into the
connectors in the backplane of the RAID subsystem.
ID 1
ID 2
ID 4
ID 8
J6
Capacity
18.0 GB (Non-RAID)
18.0 GB with SCA connector
9.1 GB (Non-RAID)
9.1 GB with SCA connector
4.3 GB (Non-RAID)
4.3 GB with SCA connector
J2
TE
Part Number
FDSK621
FDSK622
FDSK539
FDSK570
FDSK538
FDSK571
TP
PD
81
SCSI
Connector
SCSI Pin 1
Power
Connector
