Intergraph InterServe 600 Series System Setup page 17

MIDI Port
Microphone
Line Out
Ethernet Port
Keyboard Port
Mouse Port
Serial Ports
Parallel Port
Video Port
WARNING Do not connect a MIDI or game cable to the Ethernet AUI port. This could short out the
local area network on which the system resides.
CAUTION If you are not using cables supplied by Intergraph, use shielded cables to prevent excessive
electromagnetic interference (EMI). Intergraph cables are designed to reduce the amount of
EMI produced by the system.
6. If using a PC Card (PCMCIA) modem with the installed InterSite Server Monitor (ISM)
card, connect the modem cable to the port in the ISM card modem slot. If the PC Card
modem is not installed in the modem slot, refer to the InterSite Server Monitor
documentation for instructions on installing and connecting to the PC Card modem.
7. Connect the power cords for the monitor and the base unit to an Uninterruptible Power
Supply (UPS) or to a grounded, three-prong wall outlet. Then connect the power cords to
the back of the server base unit and to the monitor.
ISM Card
Modem Slot
SCSI Port
P
3
