Incorrect number of processors displays

Reason
Faulty CPU
CPU not properly seated into the socket.
Voltage Regulator Module (VRM) not
properly installed.

Incorrect amount of memory displays

Reason
Faulty SIMMs.
SIMMs not properly seated into the socket.

CD-ROM drive is not recognized

Reason
CD-ROM drive power cable not attached.
CD-ROM drive SCSI cable not attached.
SCSI termination is not disabled.
A SCSI address conflict exists between the
CD-ROM drive and another SCSI device.

I/O card parity error message displays

Reason
Faulty option board is installed in an ISA
slot.
Riser card is faulty.
Solution
Determine faulty CPU by swapping CPUs
until the faulty one is found.
Ensure all CPUs are properly installed.
Ensure all VRMs are properly installed.
Solution
Determine faulty SIMMs by swapping
SIMMs until the faulty one is found.
Open the base unit and ensure SIMMs are
properly installed.
Solution
Open the base unit and ensure power cable
is properly attached.
Open the base unit and ensure SCSI cable is
properly attached.
Disable SCSI termination. Refer to the CD-
ROM drive vendor's documentation.
Set SCSI ID to an unused value. Refer to
the CD-ROM drive vendor's
documentation.
Solution
Remove the ISA board, then restart the
server.
Call the Customer Response Center.
