Upgrading the Optical (CD/DVD) Device

1. Turn off the computer, and turn it over and remove the battery.
2. Locate the hard disk bay cover and remove screws
3. Remove the hard disk bay cover
4. Slide the hard disk in the direction of arrow
Model A
1 2
Model B
1 2
&
1 2
.
3
and lift the hard disk out of the bay.
4
3
4
Upgrading the Optical (CD/DVD) Device 6 - 7
Upgrading The Computer
.
Figure 6 - 4
Hard Disk Removal
