Disassembly
4. Take the HDD assembly out of the case.
5. Remove the screws
6. Just reverse the removal procedure to install the new HDD assembly
Jumper Setting for RAID/ATA Configuration
1. Turn off the computer, remove the battery
2. Locate the jumper at point
3. Use a bent paper clip to push the switches up to ON for RAID mode, or down to off for ATA mode.
Figure 8
HDD Cable & Case
a.
Removal
a. Remove the 4 screws.
b. Disconnect the HDD ca-
ble and lift the HDD as-
sembly out of the bay.
7. Hard Disk
• 4 Screws
2 - 12 Removing the Hard Disk Drive
-
and separate the HDD connector cable
1
4
(page 2 -
(Figure
8a).
8
b.
5
8
7
, and case
5
.
7
5) and hard disk
(page 2 -
2
6
1
4
.
6
11).
HDD System Warning
New HDD's are blank. Before
you begin make sure:
You have backed up any data
you want to keep from your old
HDD.
You have all the CD-ROMs
3
and FDDs required to install
your operating system and
programs.
If you have access to the inter-
net, download the latest appli-
cation and hardware driver
updates for the operating sys-
tem you plan to install. Copy
these to a removable medium.
