Introduction
Mainboard Overview - Bottom (Key Parts)
Figure 8
Mainboard Bottom
Key Parts
1. CPU Socket (no
CPU installed)
2. Memory Slots (no
memory installed)
3. ICH-5
4. Flash BIOS ROM
5. 1394 TSB43AB21
6. CardBus
PCI1410
7. Keyboard
Controller - KBC
H8 H8S-2149 HM
8. LPC Super I/O
NS PC87393
9. Clock Generator
10. ALC650 - Audio
Codec
1 - 10 Mainboard Overview - Bottom (Key Parts)
1
2
4
10
9
3
8
7
6
5
